The Secure PT1 X14-150 is a high-precision single-phase resistance transducer designed for accurate resistance measurement and analog signal conversion in industrial automation and process control applications. Featuring Accuracy Class 0.5, the transducer converts resistance input into two galvanically isolated mA analog outputs, ensuring reliable and stable signal transmission to PLCs, SCADA systems, DCS, and monitoring equipment. Its compact DIN rail-mounted design, configurable resistance ranges, and quick response time make it an ideal solution for industrial control panels, OEM machinery, and process monitoring systems.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 X14-150 |
| Product Type | Resistance Transducer |
| System | Single Phase |
| Measurement | Resistance |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | mA |
| Resistance Measuring Range | 0–100 Ω to 0–14 kΩ (Configurable) |
| Mounting | DIN Rail |
| Configuration | Micro USB with ConfigView Software |
| Response Time | ≤100–220 ms |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1, DIN 50022 |
| Applications | PLC Panels, SCADA Systems, Process Control, Industrial Automation, Resistance Monitoring |
