The Secure PT3 X23-151 is a high-precision three-phase AC voltage transducer designed for accurate voltage measurement and analog signal conversion in industrial power monitoring applications. With Accuracy Class 0.5, the transducer provides reliable True RMS measurements and features 2 galvanically isolated analog outputs for seamless integration with PLCs, SCADA systems, DCS, and energy management solutions. Its compact DIN rail-mounted design, configurable input/output ranges, and fast response time make it ideal for switchgear, power distribution panels, OEM equipment, and industrial automation.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT3 X23-151 |
| Product Type | AC Voltage Transducer |
| System | Three Phase |
| Measurement | AC Voltage (True RMS) |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Voltage Input | 3 × 100–415 V L-L, 3 × 57.5–240 V L-N |
| Measuring Range | 0–130% of Nominal Voltage |
| Current Input | 1 A / 5 A CT (configurable platform) |
| Frequency | 50/60 Hz |
| Mounting | DIN Rail |
| Configuration | USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Switchgear, Power Distribution Panels, PLC, SCADA, Industrial Automation, Energy Monitoring |
