The Secure PT3 X23-155 is a high-precision three-phase AC current transducer designed for accurate current measurement and analog signal conversion in industrial power monitoring applications. Featuring Accuracy Class 0.5, the transducer provides reliable True RMS current measurement and 2 galvanically isolated analog outputs for seamless integration with PLCs, SCADA systems, DCS, and energy management solutions. Its compact DIN rail-mounted design, configurable input/output ranges, and fast response time make it ideal for switchgear, motor control centers, power distribution panels, and industrial automation systems.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT3 X23-155 |
| Product Type | AC Current Transducer |
| System | Three Phase |
| Measurement | AC Current (True RMS) |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Current Input | 1 A / 5 A CT |
| Measuring Range | 0–150% of Nominal Current |
| Frequency | 50/60 Hz |
| Mounting | DIN Rail |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Switchgear, MCC, PLC Panels, SCADA Systems, Power Distribution, Industrial Automation |
