The Secure PT3 X23-127 is a high-precision three-phase AC Reactive Power Transducer designed for accurate reactive power (kVAr) measurement and analog signal conversion in industrial power monitoring systems. Featuring Accuracy Class 0.2, it delivers highly accurate True RMS measurement and provides 2 galvanically isolated analog outputs for seamless integration with PLCs, SCADA systems, DCS, and energy management platforms. Its compact DIN rail-mounted design, configurable input/output ranges, and fast response time make it ideal for switchgear, substations, power distribution panels, and industrial automation applications.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT3 X23-127 |
| Product Type | AC Reactive Power Transducer |
| System | Three Phase |
| Measurement | Reactive Power (kVAr) |
| Accuracy Class | 0.2 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (Current / Voltage) |
| Voltage Input | 3 × 100–415 V L-L (3P-3W), 3 × 57.5–240 V L-N (3P-4W) |
| Current Input | 1 A / 5 A CT |
| Frequency | 45–55 Hz or 55–65 Hz |
| Mounting | DIN Rail |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Switchgear, Power Distribution Panels, PLC, SCADA, DCS, Industrial Automation, Reactive Power Monitoring |
