The CA103 End Clamp is a precision-engineered industrial DIN rail end clamp designed for securely locking terminal block assemblies in position on DIN rails used in electrical panels, control systems, switchboards, PLC panels, automation cabinets, and industrial wiring installations. It is an essential panel accessory used to prevent terminal blocks from shifting, loosening, or moving due to vibration, wiring pressure, or maintenance activity.
In industrial electrical systems, multiple terminal blocks are mounted side by side on DIN rails to create organized wiring channels. Without a proper end clamp, terminal block assemblies may move along the rail, causing misalignment, wiring stress, poor terminal positioning, and maintenance difficulties. The CA103 solves this issue by acting as a mechanical stopping clamp, securely locking the terminal block row in place and maintaining organized panel wiring.
The functional working design of CA103 is based on a screw-tightened DIN rail locking mechanism. The clamp is installed at the end of terminal block assemblies and tightened against the DIN rail, creating strong mechanical support for the entire terminal row. This prevents movement during panel operation, vibration, cable pulling, or maintenance work.
One of the key advantages of CA103 is its heavy-duty mechanical locking performance, which improves terminal block stability and supports professional panel construction. Its compact design saves space while providing reliable end support in industrial electrical panels.
The CA103 is manufactured using industrial-grade polyamide insulated material with strong metal clamping hardware. The insulated body provides electrical safety, while the metal tightening mechanism ensures secure DIN rail locking and long-term industrial reliability.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Industrial electrical systems require:
✔ Terminal block row locking
✔ DIN rail end support
✔ Terminal movement prevention
✔ Better wiring stability
✔ Organized panel wiring
✔ Secure industrial terminal assembly
Without an end clamp, systems may face:
◆ Terminal block displacement
◆ Wiring stress problems
◆ Poor panel alignment
◆ Maintenance difficulties
◆ Terminal row movement
◆ Reduced mechanical stability
The CA103 solves these issues by providing a secure DIN rail locking end clamp for terminal block assemblies.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CA103 works on a mechanical DIN rail locking principle.
Its working design includes:
✔ End position terminal support
✔ Screw tightened locking system
✔ DIN rail mechanical gripping
✔ Terminal row stabilization
✔ Secure panel assembly support
✔ Vibration resistant locking
This creates a stable and organized terminal block assembly inside industrial electrical panels.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
◆ Heavy-duty DIN rail end clamp
◆ Secure terminal row locking
◆ Screw tightening mechanism
◆ Compact industrial design
◆ High mechanical holding strength
◆ Polyamide insulated body
◆ Corrosion resistant metal parts
◆ Easy installation design
◆ Vibration resistant support
◆ Long industrial service life
◆ Better panel organization
◆ Professional terminal block assembly support
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CA103 improves electrical panel safety by providing:
✔ Stable terminal block positioning
✔ Better panel wiring safety
✔ Reduced terminal displacement risk
✔ Improved maintenance support
✔ Secure DIN rail locking
✔ Better mechanical reliability
Its insulated design also supports safer electrical panel installation.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CA103 is manufactured using industrial-grade polyamide insulated housing with zinc plated metal tightening components.
Its construction provides:
✔ High mechanical strength
✔ Durable insulated body
✔ Corrosion resistant hardware
✔ Secure DIN rail gripping
✔ Heat resistant industrial performance
✔ Long service life
Its rugged construction supports:
✔ Vibration resistance
✔ Mechanical stress resistance
✔ Continuous industrial operation
✔ Reliable long-term performance
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CA103 improves panel wiring by providing:
✔ Stable terminal block alignment
✔ Better DIN rail support
✔ Cleaner panel layout
✔ Reduced wiring stress
✔ Easier maintenance access
✔ Professional electrical panel finishing
| Specification | Details |
|---|---|
| Product Model | CA103 |
| Product Type | DIN Rail End Clamp |
| Clamp Function | Terminal Block Row Locking |
| Mounting Compatibility | DIN 32 / DIN 35 / DIN 35-15 Rails |
| Installation Type | Screw Tightening |
| Material Type | Industrial Grade Polyamide |
| Metal Parts | Steel Zinc Plated |
| Color | Grey |
| Structural Design | End Support Clamp |
| Length | 58 mm |
| Width | 9 mm |
| Height | 54 mm |
| Mechanical Strength | High |
| Insulation Property | Non-Conductive |
| Heat Resistance | Industrial Grade |
| Moisture Resistance | Yes |
| Dust Resistance | Industrial Grade |
| Corrosion Resistance | Yes |
| Vibration Stability | Excellent |
| Mounting Stability | Secure DIN Rail Fitment |
| Maintenance Benefit | Stable Terminal Positioning |
| Service Life | Long Industrial Use |
| Main Usage | Terminal Block Locking |
| Panel Benefit | Organized Secure DIN Rail Wiring |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
► Strong DIN rail locking support
► Heavy-duty mechanical stability
► Better terminal block alignment
► Compact industrial design
► Corrosion resistant hardware
► Easy installation and maintenance
► Long industrial service life
► Professional electrical panel finishing
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✔ PLC Panels
✔ Control Panels
✔ Switchboards
✔ Automation Systems
✔ Terminal Block Assemblies
✔ Electrical Distribution Boards
✔ Machine Wiring Systems
✔ Instrumentation Panels
✔ OEM Electrical Panels
✔ Industrial Control Cabinets
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
