CA512/4-3 Ring Type Shorting Link is used for creating a secure electrical bridge between three adjacent 4 mm stud type terminal blocks in industrial electrical wiring systems. It helps distribute one common electrical circuit across multiple terminals without using separate jumper wires, reducing wiring complexity and improving panel organization. This makes it ideal for industrial control panels, switchgear systems, automation cabinets, and electrical distribution applications where safe and structured terminal commoning is required.
CA512/4-3 works as a 3 pole ring type removable shorting link that connects three adjacent terminal blocks through ring connections. Once installed under the terminal stud/nut assembly, it creates a common electrical path between connected terminals. This design allows quick installation and easy removal during maintenance or circuit modification without disturbing the complete wiring arrangement, making panel servicing faster and more convenient.
CA512/4-3 improves panel safety by creating a defined and organized common electrical circuit between adjacent terminals. Instead of loose jumper wire arrangements, the structured shorting link design reduces wiring confusion and improves maintenance visibility. Its secure mechanical fitment also minimizes chances of loose electrical connections and improves long-term operational safety in industrial electrical applications.
CA512/4-3 is manufactured using high conductivity industrial-grade metal designed for efficient current transfer and low electrical resistance. Its ring type construction provides secure mechanical holding under terminal studs, ensuring vibration-resistant electrical continuity. The rugged industrial-grade construction ensures reliable performance and long service life in demanding industrial environments.
Using CA512/4-3 helps create a clean and professional wiring arrangement inside control panels by eliminating separate jumper wire connections. It reduces panel clutter, saves installation time, improves maintenance access, and creates structured electrical commoning in industrial wiring systems.
| Specification | Details |
|---|---|
| Model Number | CA512/4-3 |
| Product Type | Ring Type Shorting Link |
| Series | CA512 |
| Number of Poles | 3 Pole |
| Connection Type | Ring Type |
| Product Function | Electrical Shorting / Commoning Link |
| Rated Current | 41 A |
| Suitable For | 4 mm Stud Type Terminal Blocks |
| Mounting Type | Terminal Stud Mounting |
| Installation Type | Under Nut / Stud Fixing |
| Material | High Conductivity Metal |
| Surface Finish | Corrosion Resistant Conductive Finish |
| Insulation Type | Uninsulated |
| Tightening Torque | 1.2 Nm |
| Quick Removal Feature | Yes |
| Reusable | Yes |
| Mechanical Fitment | Secure Ring Type Holding |
| Application Type | Terminal Block Commoning / Circuit Bridging |
| Standard Pack | 50 Nos |
| Operating Environment | Industrial Electrical Panels |
| Colour | Metallic |
CA512/4-3 is widely used in:
