CA751/3 is a compact and efficient 3 pole pre-assembled internal shorting link designed for reliable electrical commoning and simplified terminal interconnection in industrial electrical systems. This accessory enables fast bridging between adjacent compatible terminal blocks while improving wiring organization and reducing installation effort. It is widely used in industrial control panels, switchgear assemblies, automation systems, machine wiring installations, electrical cabinets, PLC systems, and power distribution applications.
The shorting link is engineered to create a secure electrical connection across multiple terminal positions without requiring additional jumper conductors. By integrating the bridging function into a single accessory, CA751/3 supports cleaner panel layouts, reduces conductor congestion, and improves service accessibility inside electrical enclosures.
This product features a pre-assembled construction, allowing direct installation without assembling separate bridging components. The integrated current bar and fixing arrangement simplify panel assembly and minimize wiring errors during installation. This ready-to-use design improves productivity and supports standardized panel manufacturing processes.
The 3 pole configuration allows electrical commoning across three adjacent terminal positions. This arrangement is useful in applications where grouped electrical distribution is required while maintaining structured conductor routing and efficient panel utilization.
Unlike traditional jumper wire methods that require additional cable preparation and manual routing, CA751/3 offers a cleaner and faster installation approach. The accessory reduces assembly time and supports consistent wiring quality across industrial projects.
The internal shorting arrangement helps maintain a neat appearance because the bridging components remain integrated within the terminal assembly instead of occupying additional wiring space. This contributes to more professional electrical cabinet construction and easier future maintenance.
CA751/3 is specifically developed for compatible 16 sq.mm feed through terminal systems, enabling dependable current distribution across grouped terminal points. The accessory supports structured electrical layouts and improves overall installation efficiency.
Installation is performed by positioning the shorting assembly into the designated terminal channel and securing it according to the recommended tightening specification. The installation method allows quick modifications during commissioning, servicing, or future panel expansion.
The shorting link supports stable electrical continuity and dependable current transfer across interconnected terminals. With a rated current capacity of 76A, the accessory is suitable for industrial electrical applications where reliable electrical commoning is required.
Its compact dimensions support better enclosure space utilization and reduce unnecessary conductor routing inside industrial panels. The modular structure also helps simplify inventory management and standardization across multiple panel configurations.
Manufactured using industrial-grade conductive materials and durable fastening components, CA751/3 delivers dependable performance under typical industrial operating conditions including vibration, thermal variations, and continuous electrical loading.
The product is commonly used in installations where multiple terminal positions must share common voltage, signal, or power distribution while maintaining structured and maintainable wiring architecture.
CA751/3 is widely applied in industrial automation panels, switchgear assemblies, PLC cabinets, machine control systems, instrumentation systems, process industries, OEM equipment manufacturing, electrical distribution systems, and industrial control applications.
Its combination of compact construction, pre-assembled design, simplified installation, and reliable electrical bridging capability makes CA751/3 a practical solution for professional industrial panel building.
| Specification | Details |
|---|---|
| Product Code | CA751/3 |
| Product Type | Pre-Assembled Shorting Link |
| Configuration | 3 Pole |
| Link Type | Internal Shorting Link |
| Rated Current | 76 A |
| Tightening Torque | 0.8 Nm |
| Installation Method | Internal Plug-In |
| Connection Type | Current Bar Assembly |
| Compatible Terminal Size | 16 sq.mm |
| Application | Terminal Commoning |
| Terminal Compatibility | Feed Through Terminal Blocks |
| Standard Pack | 50 Pieces |
Technical values compiled from published reference specifications.
CA751/3 is suitable for:
Pre-assembled design reduces panel assembly time.
Eliminates unnecessary jumper conductors.
Supports fast modifications and servicing.
Provides dependable current distribution.
Supports structured industrial wiring practices.
