Product Description
The Connectwell CDB25/3Y is a high-performance modular distribution block designed for safe and efficient power distribution in industrial control panels, switchboards, and electrical distribution systems. It features one 50 mm² input connection with a stud and bolt terminal and twelve 25 mm² screw-clamp output connections, enabling reliable power distribution from a single source to multiple outgoing circuits. The yellow polyamide housing provides easy phase identification, while the compact DIN rail mountable design ensures quick installation and long-term reliability. The CDB25/3Y is engineered to comply with IEC standards and is suitable for demanding industrial and commercial electrical applications.
Technical Specifications
Parameter Details
Product Name Distribution Block
Model CDB25/3Y
Brand Connectwell
Input Connection 1 x 50 mm²
Output Connections 12 x 25 mm²
Input Type Stud & Bolt (M8)
Output Type Screw Clamp (M5)
Rated Voltage (IEC) 800 V
Rated Voltage (UL/CSA) 600 V
Rated Current (Input) 150 A
Rated Current (Each Output) 75 A (IEC)
Housing Material Polyamide
Housing Color Yellow
Mounting Type DIN 32 / DIN 35 / DIN 35-15 Rail
Wire Entry Side Entry
Operating Temperature -40°C to +105°C
Surge Voltage 8 kV
Pollution Degree 3
UOM Each (EA)
Standard Pack 10
Minimum Order Quantity 20
Product Group B
