The CDB4/3 Distribution Terminal Block is a high-performance electrical power distribution component designed to ensure safe, organized, and efficient power management in electrical panels, switchboards, and industrial automation systems. It is widely used in industrial and commercial electrical applications where incoming electrical power needs to be distributed to multiple outgoing circuits in a secure and compact manner. Designed with high-quality insulating materials and reliable conductor terminals, the CDB4/3 offers durability, safety, and long-term performance.
In modern electrical systems, safe power distribution is one of the most critical requirements. The CDB4/3 modular distribution block is engineered to simplify this process by providing a central point where one incoming power connection can be safely divided into multiple outgoing connections. This reduces wiring complexity, improves installation efficiency, and enhances overall safety inside electrical control panels.
The CDB4/3 Distribution Terminal Block comes with a 1 x 16 sq.mm input connection and 12 x 4 sq.mm output connections, making it ideal for distributing electrical power from a single source to multiple branch circuits. This makes it highly suitable for control panels, MCC panels, PCC panels, switchgear systems, industrial machines, automation control systems, and electrical distribution boards.
Built with robust polyamide insulation housing, the terminal block ensures excellent heat resistance, flame retardant properties, and electrical insulation performance. The body is designed to withstand industrial operating conditions while maintaining safe conductor isolation. The high-quality screw-clamp connection ensures strong and vibration-resistant wire termination, reducing the risk of loose connections and electrical faults.
One of the biggest advantages of the CDB4/3 modular distribution block is its compact DIN rail mounting design. It can be easily installed on DIN 32 / DIN 35 rails, making panel assembly fast and organized. This modular mounting system saves space inside control panels and allows maintenance technicians to access and replace components easily when needed.
The rated voltage of 800V AC/DC and rated input current of 64A make this terminal block suitable for demanding industrial electrical applications. Its ability to handle high electrical loads safely makes it a preferred choice for professional electricians, panel builders, and OEM manufacturers.
Safety is another major feature of the CDB4/3 Distribution Terminal Block. It is designed with proper conductor separation and insulated housing to prevent accidental contact and short circuits. The product also offers a surge voltage resistance of 8KV, which helps protect electrical systems from voltage spikes and transient surges.
The screw clamp connection technology used in this terminal block ensures reliable wire fastening and long-term electrical contact. This minimizes maintenance requirements and improves operational stability in critical electrical systems.
Whether used in industrial machinery, building electrical systems, switchboards, renewable energy systems, or control panels, the CDB4/3 distribution block delivers reliable electrical performance and easy installation.
The CDB4/3 Distribution Terminal Block is widely used in:
| Specification | Details |
|---|---|
| Model | CDB4/3 |
| Product Type | Modular Distribution Terminal Block |
| Input Connection | 1 x 16 sq.mm |
| Output Connections | 12 x 4 sq.mm |
| Rated Voltage | 800V AC/DC |
| Rated Input Current | 64A |
| Rated Output Current | 32A |
| Surge Voltage | 8KV |
| Connection Type | Screw Clamp |
| Input Bolt Size | M5 |
| Output Screw Size | M3 |
| Wire Entry | Side Entry |
| Mounting Type | DIN Rail Mount |
| DIN Rail Compatibility | DIN 32 / DIN 35 |
| Housing Material | Polyamide |
| Color | Grey |
| Pollution Degree | 3 |
| Application | Electrical Power Distribution |
The CDB4/3 modular distribution block is designed for professionals who require safe, organized, and efficient electrical power distribution. Its compact design, high electrical ratings, secure wire termination, and DIN rail mounting make it an ideal solution for modern electrical panels.
Compared to traditional wiring methods, this distribution block improves safety, reduces installation time, minimizes wiring clutter, and enhances maintenance efficiency. Its rugged insulated housing and reliable screw clamp technology make it a trusted choice for industrial and commercial electrical systems.
For electricians, switchgear manufacturers, and panel builders, the CDB4/3 Distribution Terminal Block offers a professional and long-lasting solution for managing power distribution inside electrical enclosures.
