CDB4/4Y is a four-level feed through terminal block in yellow color specially designed for industrial electrical systems where high-density conductor termination, compact DIN rail wiring, multi-circuit distribution, and visual circuit grouping are required. In electrical control panels, PLC cabinets, switchboards, machine control systems, industrial automation assemblies, and instrumentation panels, engineers often need to connect multiple conductors in a limited wiring space while maintaining clear circuit organization.
Using standard single-level terminal blocks in such applications increases panel space requirements and creates wiring congestion. The CDB4/4Y solves this challenge by integrating four independent feed through connection levels in one compact insulated terminal body, allowing multiple circuits to be connected vertically in a single terminal assembly.
The yellow housing offers a strong visual identification advantage and is commonly used in industrial panels for special circuit grouping, caution circuit identification, maintenance reference sections, and dedicated terminal section marking, helping technicians identify important terminal groups quickly.
This terminal block is ideal for industrial applications where space-saving wiring, secure conductor retention, and organized multi-circuit management are critical.
The CDB4/4Y operates as a four-level feed through terminal block, where conductors are connected through four independent electrical paths integrated inside one compact terminal body.
Its working design provides:
The screw clamp connection system securely locks conductors and creates dependable electrical continuity, ensuring stable current transfer and reliable electrical performance.
Its four-level design makes it highly suitable for compact industrial panel wiring applications.
The yellow housing color improves visual recognition of dedicated terminal sections inside electrical panels.
Safety advantages include:
Color-coded terminal grouping improves panel safety and organization.
Yellow terminal blocks are commonly used for:
This supports structured electrical panel management.
The CDB4/4Y is manufactured using flame-retardant engineering polyamide insulation with industrial-grade conductive terminal hardware, designed for industrial electrical environments.
Construction advantages include:
Its rugged construction ensures dependable performance in demanding industrial electrical systems.
Using CDB4/4Y improves electrical panel layout by combining multiple conductor circuits into one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CDB4/4Y |
| Product Type | Four-Level Feed Through Terminal Block |
| Color | Yellow |
| Connection System | Screw Clamp |
| Number of Levels | 4 Level |
| Rated Voltage | 800 V |
| Rated Current | 32 A |
| Conductor Capacity | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Style | DIN Rail |
| Wire Entry | Side Entry |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Feed Through Multi-Circuit Terminal |
| Installation Type | Screw Tightening |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Automation Systems, Switchboards |
Supports compact high-density industrial wiring.
Reduces DIN rail usage in electrical cabinets.
Yellow housing supports dedicated circuit identification.
Screw clamp design provides reliable conductor holding.
Supports structured multi-circuit wiring layouts.
Built for demanding electrical applications.
Improves troubleshooting and servicing access.
CDB4/4Y is widely used in:
