CDB4/5(1) is a modular distribution terminal block with 12 output connections specially designed for industrial electrical systems where single input power distribution to multiple outgoing circuits, compact DIN rail installation, and organized electrical branching are required. In electrical control panels, PLC cabinets, switchboards, industrial automation systems, machine control panels, and OEM electrical assemblies, engineers often need to distribute one incoming power supply to multiple output circuits safely and efficiently.
Using jumper wires or multiple standard terminals for such applications increases wiring complexity, creates clutter, and consumes more panel space. The CDB4/5(1) solves this challenge by providing 1 central input connection and 12 distributed output connections in one compact insulated terminal body, making circuit branching simpler, safer, and more organized. This improves wiring reliability and maintenance accessibility inside industrial electrical panels.
Unlike standard distribution blocks, the (1) series design is specially configured where the input connection point is located at one end instead of the center, making it useful for panel layouts where cable routing needs side-oriented power entry. This provides installation flexibility and improves conductor management in compact electrical systems.
The CDB4/5(1) works as a modular power distribution terminal block, where a larger incoming conductor is connected through a stud & bolt input connection, and power is internally distributed to 12 outgoing screw clamp terminals.
Its working design provides:
This design reduces manual jumper wiring and creates a clean, professional power distribution arrangement inside industrial electrical panels.
The CDB4/5(1) improves electrical safety by creating a controlled and organized power distribution point inside industrial panels.
Safety advantages include:
A structured distribution block reduces wiring mistakes and improves panel safety.
The CDB4/5(1) provides several electrical panel advantages.
Benefits include:
This makes it highly suitable for industrial electrical distribution systems.
The CDB4/5(1) is manufactured using industrial-grade polyamide insulated housing with conductive distribution hardware, designed for industrial electrical environments.
Construction advantages include:
Its rugged construction ensures dependable power distribution performance in demanding industrial electrical applications.
Using CDB4/5(1) improves panel layout by replacing multiple loose branching wires with one organized modular distribution block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CDB4/5(1) |
| Product Type | Modular Distribution Terminal Block |
| Input Connections | 1 |
| Output Connections | 12 |
| Input Conductor Capacity | 6 – 16 mm² |
| Output Conductor Capacity | 0.2 – 4 mm² |
| AWG Range (Input) | 10 – 8 AWG |
| AWG Range (Output) | 22 – 10 AWG |
| Rated Voltage (IEC) | 800 V |
| Rated Current (Input Side) | 64 A |
| Rated Current (Output Side) | 32 A |
| Connection System | Stud Input + Screw Clamp Output |
| Screw Size (Output) | M3 |
| Stud Size (Input) | M5 |
| Tightening Torque (Input) | 2 Nm |
| Tightening Torque (Output) | 0.5 Nm |
| Mounting Style | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Multi-Circuit Power Distribution |
Supports efficient multi-circuit power distribution.
Improves cable routing flexibility in specific panel layouts.
Reduces DIN rail wiring congestion.
Creates clean and structured electrical layouts.
Stud input and screw clamp outputs ensure reliable conductor holding.
Built for demanding industrial environments.
Improves troubleshooting and servicing access.
CDB4/5(1) is widely used in:
