The CDB6/4BK is an industrial modular distribution block designed to simplify electrical power distribution inside control panels, switchboards, automation cabinets, and industrial installations. The model belongs to the CDB6 distribution block series, where BK represents the Black color variant. It provides a centralized incoming connection with multiple outgoing terminals, allowing efficient power branching from one source to several circuits.
The CDB6/4BK is built to reduce wiring complexity and improve installation speed in industrial environments. Instead of manually looping wires between terminals, this distribution block creates organized and secure electrical distribution through integrated internal connections. It supports one incoming connection and multiple output terminals while maintaining electrical isolation and mechanical protection.
This distribution block is widely used in:
The CDB6/4BK Modular Distribution Block is designed to distribute electrical power safely and efficiently from one main input source to multiple outputs.
Its structure includes a central bolt-type incoming connection and multiple screw-clamp outgoing terminals. This arrangement reduces cable clutter and enables faster installation during panel assembly.
The protective housing improves operator safety by covering energized components while maintaining easy access during maintenance operations. The side-entry conductor design further simplifies cable routing and panel organization.
Manufactured using durable Polyamide insulation material, the product offers excellent mechanical strength, thermal resistance, and long-term electrical reliability.
Its compact DIN rail mounting system allows integration into modern industrial control cabinets where efficient use of space is important.
Supports one incoming supply with multiple outgoing connections.
Optimizes control panel space.
Ensures stable incoming power connection.
Provides organized power branching.
Supports fast and standardized installation.
Polyamide construction for durability.
Simplifies troubleshooting and electrical servicing.
Protective housing improves operational safety.
| Specification | Details |
|---|---|
| Product Model | CDB6/4BK |
| Product Type | Modular Distribution Block |
| Series | CDB6 |
| Color | Black |
| Input Connection | 1 × 25 mm² |
| Output Connections | 16 × 6 mm² |
| Rated Voltage | 800 V |
| Rated Current (Input Side) | 82 A |
| Rated Current (Output Side) | 41 A |
| Rated Surge Voltage | 8 kV |
| Housing Material | Polyamide |
| Connection Type | Screw Clamp |
| Input Stud Size | M6 |
| Output Screw Size | M3.5 |
| Wire Range Input | 6–25 mm² |
| Wire Range Output | 1.5–6 mm² |
| Tightening Torque Input | 3 Nm |
| Tightening Torque Output | 0.8 Nm |
| Mounting Type | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Pollution Degree | 3 |
| Stripping Length | 9 mm |
| Product Function | Modular Distribution Block |
Technical specifications may vary slightly by regional approvals and manufacturer updates.
Used for organized electrical power branching inside automation panels.
Distributes incoming power efficiently to multiple outgoing circuits.
Helps reduce internal machine wiring complexity.
Provides centralized electrical connectivity.
Supports structured wiring inside electrical enclosures.
Commonly integrated into prebuilt industrial control assemblies.
Reduces manual conductor looping.
Improves cable organization.
Protective cover reduces accidental contact.
Supports compact cabinet design.
Maintains stable power distribution.
Simplifies servicing and troubleshooting.
Built for demanding industrial environments.
For proper installation:
Follow local electrical standards during installation.
