CDB6/4GN is a modular distribution terminal block designed for safe power distribution, multiple output connection, and organized electrical wiring in industrial control panels and electrical distribution systems. It is specially engineered to provide one centralized input connection with multiple output terminals, making it an ideal solution for applications where incoming power needs to be distributed safely and efficiently to multiple outgoing circuits.
The main function of CDB6/4GN is to simplify electrical distribution by allowing one incoming cable connection and multiple outgoing wire connections in a single compact distribution block. This eliminates the need for multiple loop connections and reduces wiring complexity inside control panels, switchgear systems, automation panels, and industrial electrical cabinets.
Its bolt type central input connection provides secure and stable power entry, while the multiple internally connected output terminals allow easy and reliable power distribution to connected circuits. This design improves electrical safety, enhances current distribution efficiency, and helps maintain organized panel wiring.
One of the major advantages of CDB6/4GN is its 16 output connection design, which allows a single incoming power source to be distributed across multiple outgoing circuits through one compact modular block. This helps reduce wiring clutter, save installation time, and improve electrical panel organization in industrial applications.
The built-in protective insulated shield covers the incoming connection area and improves operator safety by reducing accidental contact risk. The green colour housing makes it suitable for quick circuit identification and organized colour-coded panel wiring layouts in industrial electrical systems.
Manufactured using high-strength engineering-grade polyamide housing with industrial conductive components, CDB6/4GN provides excellent mechanical durability, reliable current transfer, low contact resistance, and long service life in demanding industrial conditions.
This modular distribution terminal block is widely used in control panels, switchgear assemblies, power distribution panels, automation systems, PLC cabinets, machine wiring, industrial electrical installations, HVAC electrical panels, and OEM electrical equipment where safe and organized power distribution is required.
CDB6/4GN is used in electrical systems where one incoming power source needs to be safely distributed to multiple outgoing circuits through a compact and organized distribution block.
✔ Single input to multiple output distribution
✔ Reduces wiring complexity
✔ Improves panel organization
✔ Provides secure current distribution
✔ Reduces loop wiring requirement
✔ Improves electrical safety
CDB6/4GN works by accepting a single incoming cable through the central bolt type input connection, which internally distributes power to 16 output terminals. Each output terminal provides a secure connection point for outgoing wires.
The internally connected conductive distribution system ensures uniform current transfer, low resistance contact, and reliable electrical continuity across all output terminals. This design allows safe and efficient power distribution from one source to multiple circuits.
⭐ Modular Distribution Terminal Block Design
⭐ Single Input with Multiple Outputs
⭐ 16 Output Connection Points
⭐ Bolt Type Central Input Connection
⭐ Secure Screw Clamp Output Terminals
⭐ Compact Space Saving Construction
⭐ Protective Insulated Shield
⭐ Low Resistance Current Distribution
⭐ Reliable Electrical Continuity
⭐ Industrial Grade Performance
CDB6/4GN improves electrical safety and organized power distribution by providing a protected and centralized distribution system inside industrial panels.
🔹 Protected incoming connection shield
🔹 Reduces loose wiring risk
🔹 Improves current distribution safety
🔹 Supports safe maintenance procedures
🔹 Reduces accidental contact risk
🔹 Improves panel reliability
The green colour housing helps in easy visual identification of specific circuit distribution points inside electrical panels.
✔ Quick circuit identification
✔ Improves wiring organization
✔ Supports colour coded panel wiring
✔ Reduces maintenance errors
✔ Faster troubleshooting
✔ Professional panel appearance
CDB6/4GN is manufactured using high-strength polyamide insulated housing with industrial-grade conductive components for safe and long-lasting industrial performance.
✅ Durable industrial-grade housing
✅ Strong bolt type input design
✅ Secure output screw connections
✅ Protective insulated shield
✅ Compact modular construction
✅ Long service life durability
The compact modular distribution design of CDB6/4GN helps improve electrical panel wiring by replacing multiple manual loop connections with a single organized distribution block.
✔ Saves wiring space
✔ Reduces panel clutter
✔ Improves cable management
✔ Supports cleaner wiring layout
✔ Faster installation
✔ Simplifies maintenance
✔ Professional panel appearance
