The CF4U6 is a high-performance feed through terminal block specially designed for industrial electrical wiring, control panels, automation systems, switchgear assemblies, and power distribution applications. Engineered for reliable electrical connectivity and long-lasting industrial performance, this terminal block offers secure screw clamp connections, compact construction, and excellent insulation properties for demanding industrial environments.
The CF4U6 terminal block is manufactured using premium-quality polyamide insulation material that provides excellent thermal resistance, flame resistance, and electrical insulation. Its durable housing ensures stable operation even under continuous industrial usage and harsh environmental conditions.
Designed with a secure screw clamp mechanism, the CF4U6 offers strong wire holding capability and reliable electrical continuity. This connection system minimizes the chances of loose wiring caused by vibrations, thermal expansion, or mechanical stress, making it highly suitable for industrial automation and control applications.
Its compact 6 mm width helps optimize space inside electrical panels while maintaining excellent current carrying performance. The terminal block supports conductor sizes up to 4 sq.mm and enables organized, safe, and efficient wiring arrangements.
The terminal block is compatible with standard DIN 35 and DIN 35-15 mounting rails, allowing quick and secure installation inside control cabinets and switchgear assemblies. The user-friendly design simplifies maintenance and troubleshooting operations in industrial electrical systems.
The CF4U6 is widely used in:
Its robust industrial construction ensures dependable performance for long-term operations where electrical safety and wiring reliability are critical. The terminal block is designed to deliver stable current transmission with minimal voltage loss, making it suitable for modern industrial infrastructure.
The screw clamp design allows quick conductor termination using standard tools, reducing installation time and improving maintenance efficiency. The terminal block also supports proper cable organization, helping maintain clean and professional electrical panel layouts.
The CF4U6 terminal block is ideal for electricians, automation engineers, panel builders, and industrial system integrators looking for a reliable and compact wiring solution for industrial applications.
| Parameter | Specification |
|---|---|
| Model Number | CF4U6 |
| Product Type | Feed Through Terminal Block |
| Rated Voltage | 1000 V |
| Rated Current | 32 A |
| Connection Type | Screw Clamp |
| Wire Range | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide |
| Number of Connections | 2 |
| Number of Levels | 1 |
| Width | 6 mm |
| Wire Entry Orientation | Side Entry |
| Tightening Torque | 0.5 – 0.8 Nm |
| Stripping Length | 8 – 10 mm |
| Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Color | Grey |
| Operating Method | Screwdriver |
The slim 6 mm body allows efficient panel space utilization for high-density wiring applications.
Strong screw clamp technology ensures stable and vibration-resistant wiring connections.
High-quality polyamide housing provides long-term mechanical and thermal stability.
Supports quick installation on standard DIN rails used in industrial electrical systems.
Suitable for continuous operations in automation, switchgear, and power distribution systems.
