The CF4UL110-240V1.0 is a precision-engineered LED fuse terminal block designed for secure electrical connectivity, efficient fuse monitoring, and reliable circuit protection in industrial automation and control systems. Developed for modern industrial applications, this terminal block combines advanced fuse disconnect functionality with integrated LED indication to provide enhanced operational safety and maintenance efficiency.
Manufactured using high-quality flame-retardant polyamide material, the CF4UL110-240V1.0 offers superior electrical insulation, excellent thermal resistance, and long-term mechanical durability. Its rugged industrial-grade construction ensures dependable performance even in harsh environments exposed to vibration, heat, and continuous industrial operation.
This terminal block is configured with a 1.0A fuse rating, making it suitable for low-current industrial circuits and sensitive control applications requiring accurate electrical protection. It effectively safeguards automation equipment, instrumentation systems, sensors, PLC circuits, and control devices against overloads and short-circuit conditions.
One of the major highlights of the CF4UL110-240V1.0 is its integrated 110-240V LED indication system. The built-in LED provides instant visual monitoring of fuse condition, allowing maintenance engineers and technicians to quickly identify fuse failures or interrupted circuits. This significantly reduces troubleshooting time and improves maintenance productivity in industrial operations.
Designed to support 4 sq.mm conductor capacity, the terminal block ensures stable current transfer and organized wiring inside industrial control cabinets and electrical distribution panels. Its compact modular design supports efficient panel space utilization and clean electrical layouts in high-density installations.
The CF4UL110-240V1.0 features a secure screw clamp connection system that provides strong conductor retention and vibration-resistant electrical connectivity. This minimizes the risk of loose wiring connections and ensures stable electrical performance during continuous industrial usage.
Its side-entry wire connection design simplifies installation, conductor insertion, and maintenance procedures. The terminal block is fully compatible with standard DIN rail mounting systems, enabling quick and organized installation inside automation panels and industrial electrical systems.
The CF4UL110-240V1.0 is widely used across industries such as industrial automation, instrumentation engineering, machine manufacturing, process control systems, renewable energy systems, HVAC systems, factory automation projects, and electrical distribution applications.
Its combination of 1.0A precision fuse protection, LED monitoring capability, durable insulated housing, and compact DIN rail design makes it an ideal solution for industrial systems requiring safe electrical protection and organized panel integration.
The CF4UL110-240V1.0 delivers dependable fuse protection, efficient maintenance support, and stable industrial electrical performance for modern automation and control applications.
| Specification | Details |
|---|---|
| Product Model | CF4UL110-240V1.0 |
| Product Type | LED Fuse Terminal Block |
| Fuse Rating | 1.0 A |
| Voltage Range | 110-240V |
| Conductor Capacity | 4 Sq.mm |
| Mounting Type | DIN Rail Mounting |
| Connection Type | Screw Clamp |
| LED Indicator | Yes |
| Fuse Protection | Yes |
| Housing Material | Flame Retardant Polyamide |
| Wire Entry | Side Entry |
| Installation Type | Panel Mounted |
| Operating Temperature | -40°C to +105°C |
| Industrial Usage | Precision Electrical Protection |
| Application | Automation & Instrumentation Systems |
| HSN Code | 85389000 |
| Brand | Connectwell |
| Country of Origin | India |
The CF4UL110-240V1.0 is suitable for industrial systems requiring reliable low-current fuse protection and efficient fault monitoring.
Its 1.0A fuse configuration makes it highly suitable for precision industrial electrical systems and control equipment protection.
The 1.0A fuse configuration helps protect sensitive industrial circuits and control devices.
Integrated LED indication allows quick identification of fuse failures and interrupted circuits.
Protects connected equipment against overloads and short-circuit conditions.
Space-saving modular structure supports organized high-density electrical installations.
Strong screw clamp mechanism ensures stable and vibration-resistant conductor termination.
Quick mounting compatibility simplifies electrical panel assembly and maintenance work.
Built using premium insulated material for dependable long-term industrial operation.
The CF4UL110-240V1.0 is designed for industrial systems requiring reliable low-current fuse protection and organized electrical connectivity.
Professionals prefer this terminal block because of:
Its dependable industrial performance makes it ideal for instrumentation systems, automation panels, and precision electrical control applications.
