The CF4UL6-60VRP is a high-performance LED fuse terminal block designed for reliable circuit protection, safe fuse handling, and efficient fault indication in industrial electrical applications. This DIN rail mounted terminal block is widely used in PLC panels, industrial automation systems, switchgear assemblies, control cabinets, instrumentation systems, and machine control applications where secure electrical protection is essential.
Equipped with an integrated LED indication system, the CF4UL6-60VRP allows maintenance engineers and technicians to quickly identify blown fuses, reducing troubleshooting time and minimizing operational downtime. The terminal block supports standard cartridge fuses and provides dependable overcurrent protection for sensitive electrical circuits and automation equipment.
Its compact modular design supports organized wiring and efficient panel space utilization in modern industrial control systems. Manufactured using industrial-grade polyamide material, the CF4UL6-60VRP offers excellent insulation strength, thermal resistance, and mechanical durability for continuous industrial operation.
The red housing body with LED indication improves circuit identification and helps maintain professional electrical panel organization.
The CF4UL6-60VRP fuse terminal block is specially engineered for industrial electrical installations where reliable fuse protection and visual fault monitoring are important. It combines secure conductor connectivity with fast fuse status indication, improving maintenance efficiency and operational safety.
The built-in LED indication illuminates automatically when the fuse fails, helping technicians quickly locate faulty circuits without using additional testing equipment. This feature is highly useful in automation systems, process control panels, and machine control circuits where minimizing downtime is critical.
Its screw clamp connection system ensures strong conductor holding and vibration-resistant electrical performance in harsh industrial environments. The enclosed fuse compartment enhances safety by protecting the fuse from accidental contact and external environmental exposure.
The compact DIN rail mounted design supports easy installation and clean panel layouts in industrial automation systems, power distribution panels, and OEM electrical assemblies.
| Specification | Details |
|---|---|
| Model Number | CF4UL6-60VRP |
| Product Type | LED Fuse Terminal Block |
| Mounting Type | DIN Rail Mounting |
| Rated Voltage | 800 V |
| Rated Current | 6.3 A |
| Voltage Range | 6V – 60V |
| Fuse Type | Glass Cartridge Fuse |
| Fuse Size | 5x20 mm / 5x25 mm |
| Wire Size Range | 0.2 sq.mm to 4 sq.mm |
| Maximum Conductor Size | 6 sq.mm |
| Connection Technology | Screw Clamp |
| Housing Material | Polyamide |
| Wiring Direction | Side Entry |
| Width | 8 mm |
| Length | 57 mm |
| LED Indication | Available |
| Fuse Chamber | Fully Enclosed |
| Color | Red |
| Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Industrial Usage | Automation & Control Panels |
The CF4UL6-60VRP fuse terminal block is suitable for industrial electrical systems requiring safe fuse protection and fast maintenance access.
Its LED indication feature makes it highly suitable for systems where quick troubleshooting and reduced downtime are important.
The built-in LED indication instantly shows fuse failure, helping maintenance teams quickly identify faulty circuits.
The fuse terminal block protects electrical systems against overloads and short circuits.
Its slim modular structure helps save space inside industrial control panels.
Quick fuse access and LED indication simplify maintenance and troubleshooting operations.
The screw clamp system ensures stable conductor holding and dependable current flow.
The industrial-grade polyamide housing provides excellent resistance against heat, vibration, and mechanical stress.
The enclosed fuse compartment improves safety by protecting users from accidental fuse contact.
Fuse terminal blocks are essential components in industrial electrical systems because they combine conductor connectivity and circuit protection in a single compact unit. They simplify panel wiring while protecting sensitive electrical equipment from overload and short circuit conditions.
The CF4UL6-60VRP improves maintenance efficiency through its integrated LED fault indication system, allowing maintenance engineers to quickly identify blown fuses and restore operations faster.
Its DIN rail mounted compact structure also supports organized and professional electrical panel layouts in modern industrial automation systems.
The CF4UL6-60VRP offers an excellent combination of reliable fuse protection, compact installation, and fast maintenance access. Its LED indication system, durable housing, secure screw clamp technology, and enclosed fuse compartment make it an ideal solution for industrial automation and control applications.
This terminal block provides dependable long-term performance in industrial environments exposed to vibration, heat, and continuous electrical operation. It is widely preferred by electrical engineers, panel builders, automation specialists, and OEM manufacturers.
