The CF4UL6-60VRPBK is a compact and industrial-grade LED fuse terminal block designed for reliable circuit protection and secure electrical connectivity in industrial automation and control systems. This DIN rail mounted fuse terminal block is widely used in PLC panels, electrical control cabinets, instrumentation systems, switchgear assemblies, process automation systems, and machine control applications where safe fuse protection is required.
Equipped with an integrated LED indication system, the CF4UL6-60VRPBK enables quick identification of blown fuses, helping maintenance engineers reduce troubleshooting time and improve operational efficiency. The terminal block supports industry-standard cartridge glass fuses and delivers dependable overcurrent protection for sensitive electrical circuits.
Its fully enclosed fuse chamber improves operator safety and eliminates the need for separate end plates. The black housing color supports organized circuit identification and professional wiring layouts in industrial electrical panels.
Manufactured using durable polyamide insulation material, the CF4UL6-60VRPBK offers excellent thermal resistance, insulation performance, and long-term reliability under demanding industrial conditions.
The CF4UL6-60VRPBK fuse terminal block is specially engineered for industrial electrical systems where fuse protection, compact installation, and fast maintenance access are important. The built-in LED indicator lights up in case of fuse failure, allowing technicians to identify faulty circuits instantly without using additional testing equipment.
The terminal block uses a screw clamp connection mechanism that ensures strong conductor holding and stable electrical performance even in environments exposed to vibration and continuous operation. Its side-entry wiring arrangement simplifies conductor installation while maintaining clean and organized panel layouts.
Compatible with DIN 32, DIN 35, and DIN 35-15 rails, the CF4UL6-60VRPBK supports flexible installation across different industrial control systems and automation panels.
The product is suitable for industrial automation systems, electrical distribution panels, renewable energy systems, machine control equipment, OEM electrical assemblies, and process control applications.
| Specification | Details |
|---|---|
| Model Number | CF4UL6-60VRPBK |
| Product Type | LED Fuse Terminal Block |
| Function | Single Level Fuse Terminal |
| Rated Voltage | 800 V |
| Rated Current | 6.3 A |
| Voltage Range | 6V – 60V |
| Rated Surge Voltage | 8 kV |
| Fuse Type | Glass Cartridge Fuse |
| Fuse Size | 5 x 20 mm / 5 x 25 mm |
| Wire Size Range | 0.2 sq.mm to 4 sq.mm |
| Maximum Solid Conductor Size | 6 sq.mm |
| Connection Technology | Screw Clamp |
| Tightening Torque | 0.5 Nm |
| Mounting Compatibility | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide |
| Screw Size | M3 |
| Wiring Orientation | Side Entry |
| Width | 8 mm |
| Length | 57 mm |
| LED Indication | Yes |
| Pollution Degree | 3 |
| Color | Black |
| Operation | Screwdriver Operated |
Technical specifications verified from industrial product datasheets and manufacturer references.
The CF4UL6-60VRPBK is widely used in industrial electrical systems requiring safe fuse protection and fast maintenance access.
Its LED indication feature makes it especially useful for systems where minimizing downtime and simplifying maintenance are important.
The integrated LED indication instantly displays fuse failure, helping maintenance teams quickly identify faulty circuits.
The fuse terminal block protects electrical systems against overload and short-circuit conditions.
Quick fuse access and visual indication simplify troubleshooting and reduce maintenance time.
Its slim modular structure supports efficient panel space utilization and organized wiring layouts.
The screw clamp system ensures stable conductor holding and dependable electrical performance.
The polyamide housing provides excellent resistance against heat, vibration, and mechanical stress.
The enclosed fuse chamber minimizes accidental contact with live fuse components.
Fuse terminal blocks are essential components in industrial automation and electrical control systems because they combine conductor connectivity and circuit protection in a single compact device. The CF4UL6-60VRPBK improves operational safety and simplifies panel wiring while protecting sensitive equipment from overload conditions.
The integrated LED indication system allows technicians to quickly locate blown fuses, minimizing production downtime and improving troubleshooting efficiency. Its compact DIN rail mounted structure also supports professional and organized electrical panel installations.
The CF4UL6-60VRPBK offers an excellent combination of reliable fuse protection, compact design, industrial durability, and easy maintenance access. Its LED fault indication, enclosed fuse compartment, and secure screw clamp connection system make it ideal for industrial automation and control applications.
The terminal block provides dependable long-term performance in industrial environments exposed to vibration, heat, and continuous electrical operation. It is widely preferred by electrical engineers, industrial electricians, automation professionals, and OEM panel manufacturers.
