The CF4UL6-60VY is a high-quality LED fuse terminal block designed for reliable circuit protection and safe electrical connectivity in industrial automation and control systems. This DIN rail mounted fuse terminal block is widely used in PLC panels, electrical control cabinets, instrumentation systems, switchgear assemblies, machine control panels, and process automation applications where secure fuse protection is essential.
Equipped with an integrated LED indication system, the CF4UL6-60VY enables fast identification of blown fuses, helping maintenance engineers reduce troubleshooting time and minimize industrial downtime. The terminal block supports standard cartridge glass fuses and provides dependable overcurrent protection for sensitive industrial electrical circuits and automation equipment.
Its compact modular design supports organized wiring and efficient panel space utilization in modern industrial control systems. The yellow housing color simplifies circuit identification and improves maintenance accessibility in complex electrical installations.
Manufactured using industrial-grade polyamide material, the CF4UL6-60VY offers excellent insulation strength, thermal resistance, and mechanical durability for long-term industrial operation.
The CF4UL6-60VY fuse terminal block is specially engineered for industrial electrical systems where fuse protection, compact installation, and quick maintenance access are important. The built-in LED indication illuminates automatically when the fuse fails, allowing technicians to instantly identify faulty circuits without additional testing devices.
Its screw clamp connection technology provides strong conductor holding and vibration-resistant electrical performance in demanding industrial environments exposed to heat, vibration, and continuous operation. The side-entry wiring arrangement simplifies conductor installation and supports organized electrical panel layouts.
The fully enclosed fuse compartment improves operational safety by protecting the fuse from accidental contact and external environmental conditions. Compatible with DIN 32, DIN 35, and DIN 35-15 mounting rails, the CF4UL6-60VY offers flexible installation options across different industrial electrical systems.
The terminal block is suitable for industrial automation systems, process control equipment, renewable energy systems, OEM electrical assemblies, and factory automation applications.
| Specification | Details |
|---|---|
| Model Number | CF4UL6-60VY |
| Product Type | LED Fuse Terminal Block |
| Function | Single Level Fuse Terminal |
| Rated Voltage | 800 V |
| Rated Current | 6.3 A |
| Voltage Range | 6V – 60V |
| Rated Surge Voltage | 8 kV |
| Fuse Type | Glass Cartridge Fuse |
| Fuse Size | 5 x 20 mm / 5 x 25 mm |
| Wire Size Range | 0.2 sq.mm to 4 sq.mm |
| Maximum Solid Conductor Size | 6 sq.mm |
| Connection Technology | Screw Clamp |
| Tightening Torque | 0.5 Nm |
| Mounting Compatibility | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide |
| Screw Size | M3 |
| Wiring Orientation | Side Entry |
| Width | 8 mm |
| Length | 57 mm |
| LED Indication | Yes |
| Pollution Degree | 3 |
| Color | Yellow |
| Operation | Screwdriver Operated |
| Industrial Usage | Automation & Control Panels |
The CF4UL6-60VY fuse terminal block is widely used in industrial electrical systems requiring safe fuse protection and fast maintenance access.
Its LED indication feature makes it highly suitable for systems where minimizing downtime and simplifying troubleshooting are important.
The integrated LED indication instantly displays fuse failure, helping maintenance teams quickly identify faulty circuits.
The fuse terminal block protects electrical systems against overload and short-circuit conditions.
Quick fuse access and visual indication simplify troubleshooting and reduce maintenance time.
Its slim modular structure supports efficient panel space utilization and organized wiring layouts.
The screw clamp system ensures stable conductor holding and dependable electrical performance.
The polyamide housing provides excellent resistance against heat, vibration, and mechanical stress.
The enclosed fuse chamber minimizes accidental contact with live fuse components.
Fuse terminal blocks are essential components in industrial automation and electrical control systems because they combine conductor connectivity and circuit protection in a single compact device. The CF4UL6-60VY improves operational safety and simplifies panel wiring while protecting sensitive equipment from overload conditions.
The integrated LED indication system allows technicians to quickly locate blown fuses, minimizing production downtime and improving troubleshooting efficiency. Its compact DIN rail mounted structure also supports professional and organized electrical panel installations.
The CF4UL6-60VY offers an excellent combination of reliable fuse protection, compact design, industrial durability, and easy maintenance access. Its LED fault indication, enclosed fuse compartment, and secure screw clamp connection system make it ideal for industrial automation and control applications.
The terminal block provides dependable long-term performance in industrial environments exposed to vibration, heat, and continuous electrical operation. It is widely preferred by electrical engineers, industrial electricians, automation professionals, and OEM panel manufacturers.
