CMC1-2 is an end clamp / terminal fixing accessory specially designed for DIN rail mounted terminal block assemblies where secure terminal locking, rail-end support, and panel stability are essential. In electrical control panels, PLC cabinets, switchboards, automation systems, and industrial wiring assemblies, terminal blocks mounted on DIN rails need to be held firmly in position to prevent shifting during wiring, maintenance, or machine vibration.
The CMC1-2 is used at the end of a terminal block assembly to lock the complete row of terminals securely in place. Without an end clamp, terminal blocks can slide on the DIN rail, causing misalignment, wiring stress, and maintenance difficulties. This accessory provides a reliable mechanical stop, ensuring that all mounted terminals remain properly positioned.
It is an important panel accessory for professional electrical installations where stable terminal mounting and organized DIN rail management are required.
The CMC1-2 works as a mechanical DIN rail end clamp, mounted at the edge of a terminal block assembly to hold the terminal row securely against movement.
Its functional design provides:
Once installed and tightened, the CMC1-2 acts as a rigid end support that prevents terminals from shifting during wiring or industrial vibration.
The CMC1-2 improves panel safety by keeping terminal blocks securely fixed in their proper position.
Safety advantages include:
A secure terminal assembly helps reduce maintenance issues and improves wiring reliability.
The CMC1-2 end clamp provides essential DIN rail assembly benefits.
Benefits include:
This makes terminal block assemblies safer and more professional.
The CMC1-2 is manufactured using industrial-grade insulated engineering material with strong mechanical locking hardware, designed for heavy-duty electrical panel use.
Construction advantages include:
Its rugged construction ensures dependable terminal fixing performance.
Using CMC1-2 improves electrical panel organization by locking terminal rows in a fixed and structured position.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CMC1-2 |
| Product Type | End Clamp / Terminal Fixing Accessory |
| Application | DIN Rail Terminal Block Locking |
| Function | Terminal Row End Support |
| Material | Industrial Grade Engineering Plastic / Metal Hardware |
| Mounting Type | DIN Rail End Mount |
| Fixing Method | Screw Tightening |
| Mechanical Strength | High |
| Heat Resistance | Industrial Standard |
| Durability | Long Service Life |
| Terminal Function | Anti-Sliding Terminal Lock |
| Installation | Easy Fit |
| Industrial Use | Panels, Switchboards, PLC Systems |
Prevents terminal blocks from sliding on DIN rail.
Keeps terminal assemblies aligned and fixed.
Simple mounting and tightening design.
Reduces wiring stress caused by terminal movement.
Built for long-term industrial panel use.
Maintains organized terminal row structure.
Supports clean and stable electrical panel layouts.
CMC1-2 is widely used in:
