CMC1-2R is a red end clamp / DIN rail terminal locking accessory specially designed for industrial electrical terminal assemblies where terminal row stability, secure DIN rail locking, and organized electrical panel mounting are essential. In electrical control panels, switchboards, PLC cabinets, industrial automation systems, and distribution boards, terminal blocks mounted on DIN rails must remain firmly fixed in place. Without a secure end clamp, terminal blocks may shift during wiring, vibration, maintenance, or long-term machine operation.
The CMC1-2R is used as a mechanical end stop installed at the end of a terminal block row to lock the complete terminal assembly securely in position. This prevents sliding movement on the DIN rail, maintains proper terminal alignment, and protects wiring from mechanical stress caused by terminal shifting.
The red body color also provides a visual identification advantage and is often used in industrial electrical panels for warning circuit sections, emergency control terminal rows, dedicated circuit grouping, or critical wiring identification, making panel maintenance and troubleshooting easier.
The CMC1-2R works as a DIN rail mounted end clamp, fixed at the edge of terminal block assemblies to hold the entire row securely against movement.
Its working design provides:
Once tightened, the clamp acts as a rigid mechanical stop, ensuring that terminal blocks remain fixed even in vibration-prone industrial environments.
This improves panel reliability and terminal assembly safety.
The red color coding improves visual recognition of dedicated or critical terminal sections.
Safety advantages include:
This helps technicians identify critical terminal rows quickly during maintenance.
Red accessories are commonly used in industrial electrical panels for:
This improves structured electrical panel design.
The CMC1-2R is manufactured using industrial-grade engineering plastic with strong metal locking hardware, designed for industrial electrical applications.
Construction advantages include:
Its rugged construction ensures dependable terminal fixing performance.
Using CMC1-2R improves panel layout by securing terminal rows and maintaining organized DIN rail assemblies.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CMC1-2R |
| Product Type | End Clamp / Terminal Locking Accessory |
| Color | Red |
| Application | DIN Rail Terminal Block Locking |
| Function | Terminal Row End Support |
| Material | Industrial Grade Engineering Plastic / Metal Hardware |
| Mounting Type | DIN Rail End Mount |
| Fixing Method | Screw Tightening |
| Mechanical Strength | High |
| Heat Resistance | Industrial Standard |
| Durability | Long Service Life |
| Terminal Function | Anti-Sliding Terminal Lock |
| Installation | Easy Fit |
| Industrial Use | Panels, Switchboards, PLC Systems |
Prevents terminal blocks from sliding on DIN rail.
Red body supports dedicated circuit grouping.
Keeps terminal rows aligned and fixed.
Simple mounting and tightening design.
Built for long-term electrical panel use.
Supports organized terminal row structure.
Creates clean and stable electrical layouts.
CMC1-2R is widely used in:
