CMC2-2BU is a blue multiple connection terminal block specially designed for industrial electrical systems where multiple conductor termination in a single terminal, compact DIN rail installation, and organized neutral circuit distribution are required. In electrical control panels, PLC cabinets, switchboards, industrial automation systems, instrumentation panels, and machine control assemblies, engineers often need to connect more than one conductor at the same potential point without using multiple separate terminal blocks.
Using standard feed-through terminals for such applications increases wiring complexity, consumes more panel space, and creates cluttered layouts. The CMC2-2BU solves this challenge by providing four connection points in one compact terminal block, allowing multiple conductors to be terminated and electrically interconnected through a single conductor path.
The blue housing provides a strong visual identification advantage and is commonly used for neutral circuit distribution, dedicated wiring sections, and organized panel grouping, helping technicians identify terminal sections quickly during maintenance and troubleshooting.
This terminal block is ideal for industrial applications where multi-wire connection, compact panel wiring, and reliable electrical continuity are essential.
The CMC2-2BU operates as a multiple connection terminal block, where four conductor entry points are internally connected through a common conductive path.
Its working design provides:
Instead of using several separate terminals for one common connection, the CMC2-2BU allows multiple conductors to be connected safely within one compact terminal body, reducing panel space and simplifying wiring.
This creates an efficient and organized industrial wiring solution.
The blue housing color improves visual recognition of dedicated terminal sections inside electrical panels.
Safety advantages include:
Color-based terminal grouping improves panel safety and wiring organization.
Blue terminal blocks are commonly used for:
This supports structured electrical panel management.
The CMC2-2BU is manufactured using flame-retardant polyamide housing with industrial-grade conductive terminal hardware, designed for demanding industrial electrical applications.
Construction advantages include:
Using CMC2-2BU improves electrical panel layout by combining multiple conductor connections into one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CMC2-2BU |
| Product Type | Multiple Connection Terminal Block |
| Color | Blue |
| Connection Points | 4 |
| Rated Voltage | 630 V |
| Rated Current | 32 A |
| Conductor Capacity | 0.2 – 4 mm² |
| Solid Conductor Capacity | 0.2 – 6 mm² |
| AWG Range | 22 – 10 AWG |
| Connection System | Screw Clamp |
| Screw Size | M3 |
| Tightening Torque | 0.5 Nm |
| Mounting Style | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 6 mm |
| Length | 65 mm |
| Electrical Function | Multiple Wire Common Connection |
| Industrial Use | PLC Panels, Switchboards, Automation Systems |
Supports compact multi-wire distribution.
Reduces DIN rail usage in electrical cabinets.
Blue housing supports quick identification.
Screw clamp design provides reliable conductor holding.
Supports clean and structured wiring layouts.
Built for demanding electrical applications.
Improves troubleshooting and servicing access.
CMC2-2BU is widely used in:
