CMC2-2GN is a green multiple connection terminal block specially designed for industrial electrical systems where multiple conductor termination in a single terminal, compact DIN rail installation, and dedicated grounding or special circuit grouping are required. In electrical control panels, PLC cabinets, switchboards, industrial automation systems, machine control panels, and instrumentation assemblies, engineers often need to connect multiple conductors at one common electrical point without using several separate terminals.
Using standard feed-through terminal blocks in such applications increases wiring complexity, consumes more panel space, and creates cluttered electrical layouts. The CMC2-2GN solves this problem by providing 4 connection points in one compact terminal block, where all the conductor entry points are internally connected through a single conductive path, allowing multiple conductors to be terminated safely and efficiently in one terminal.
The green housing provides a visual identification advantage and is commonly used for grounding-related circuits, dedicated circuit sections, and special panel wiring identification, helping technicians quickly identify specific terminal sections during maintenance and troubleshooting. This makes it highly suitable for industrial electrical systems where multi-wire connection, organized circuit distribution, and reliable electrical continuity are essential.
The CMC2-2GN works as a multiple connection terminal block, where four conductor entry points are internally connected through a common conductive path.
Its working design provides:
Instead of using several separate terminals for one common connection, the CMC2-2GN allows multiple conductors to be connected safely within one compact terminal body, reducing panel space and simplifying wiring management.
The green housing color improves visual recognition of dedicated terminal sections inside electrical panels.
Safety advantages include:
Color-based terminal grouping improves electrical panel safety and maintenance efficiency.
Green terminal blocks are commonly used for:
This supports structured electrical panel management.
The CMC2-2GN is manufactured using flame-retardant polyamide housing with industrial-grade conductive terminal hardware, designed for demanding industrial electrical applications.
Construction advantages include:
Using CMC2-2GN improves electrical panel layout by combining multiple conductor connections into one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CMC2-2GN |
| Product Type | Multiple Connection Terminal Block |
| Color | Green |
| Connection Points | 4 |
| Rated Voltage | 630 V |
| Rated Current | 32 A |
| Conductor Capacity (Stranded) | 0.2 – 4 mm² |
| Conductor Capacity (Solid) | 0.2 – 6 mm² |
| AWG Range | 22 – 10 AWG |
| Connection System | Screw Clamp |
| Screw Size | M3 |
| Tightening Torque | 0.5 Nm |
| Mounting Style | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 6 mm |
| Length | 65 mm |
| Electrical Function | Multiple Wire Common Connection |
| Industrial Use | PLC Panels, Switchboards, Automation Systems |
Supports compact multi-wire distribution.
Reduces DIN rail usage in electrical cabinets.
Green housing supports quick identification.
Screw clamp design provides reliable conductor holding.
Supports clean and structured wiring layouts.
Built for demanding electrical applications.
Improves troubleshooting and servicing access.
CMC2-2GN is widely used in:
