3Y Modular Distribution Terminal Block is commonly used in:
| Specification | Details |
|---|---|
| Model Number | CMDB10/3Y |
| Product Type | Modular Distribution Terminal Block |
| Rated Voltage | 1000V |
| Rated Current | 57A |
| Input Connection | 1 Input |
| Output Connections | 6 x 10 sq.mm |
| Conductor Range | 1.5 – 10 sq.mm |
| Housing Material | Polyamide |
| Color | Yellow |
| Mounting Type | DIN Rail Mounting |
| DIN Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Wire Entry Orientation | Side Entry |
| Screw Size | M4 |
| Rated Surge Voltage | 8KV |
| Pollution Degree | 3 |
| Length | 48 mm |
| Applications | Control Panels, Distribution Boards, Switchgear |
✅ Compact space-saving modular design
✅ Efficient 1 input to 6 output power distribution
✅ High 57A current carrying capacity
✅ Supports 1000V rated voltage
✅ Strong insulated polyamide housing
✅ Easy DIN rail mounting installation
✅ Secure screw clamp wire connection
✅ Side-entry wiring for easy cable management
✅ Reduces panel wiring complexity
✅ Improves electrical safety and reliability
✅ Suitable for industrial and commercial applications
✅ Long-lasting durable construction
