CDINSW2 DIN Rail Mounting Socket & Switch is used to provide a safe and convenient auxiliary power outlet inside industrial electrical panels, switchgear assemblies, control cabinets, and automation systems. It combines a socket with a double pole switch in one compact DIN rail mountable unit, allowing operators and maintenance engineers to connect portable tools, testing equipment, and service devices directly inside the electrical panel. This reduces the need for external power arrangements and creates a cleaner, more organized panel layout.
CDINSW2 works as a DIN rail mounted socket with integrated 2 pole switch that provides controlled power access inside industrial electrical panels. The unit is connected to the panel supply through terminal connections and mounted directly onto a standard DIN rail. The double pole switch disconnects both live and neutral lines simultaneously, ensuring safer operation and improved electrical isolation during maintenance and servicing.
CDINSW2 improves electrical safety by providing a dedicated and controlled power outlet inside industrial panels. The double pole switch design isolates both live and neutral lines for better operator protection. This reduces unsafe temporary wiring practices and creates a safer service power point for maintenance and testing applications.
CDINSW2 is manufactured using high-quality polycarbonate housing that offers excellent insulation, flame resistance, and impact durability. The internal brass contacts and wire clamps ensure reliable conductivity and long service life. Its ABS DIN rail mounting frame provides secure mechanical stability and strong mounting performance in industrial environments.
Using CDINSW2 improves panel organization by creating an integrated socket and switch power point directly on the DIN rail. It eliminates separate socket mounting cut-outs, reduces panel wiring complexity, saves installation space, and improves the overall professional appearance of control panels and switchgear systems.
| Specification | Details |
|---|---|
| Model Number | CDINSW2 |
| Product Type | DIN Rail Mounting Socket with Double Pole Switch |
| Switch Configuration | 2 Pole |
| Rated Voltage | 250 V AC |
| Rated Current | 6 A |
| Socket Type | DIN Rail Mounted Service Socket |
| Connection Type | Screw Clamp |
| Conductor Size | 0.5 – 2.5 mm² |
| Operating Frequency | 50/60 Hz |
| Housing Material | Polycarbonate |
| DIN Rail Frame Material | ABS |
| Contact Material | Brass |
| Wire Clamp Material | Brass |
| Height | 82 mm |
| Width | 54 mm |
| Depth | 65 mm |
| Mounting Type | DIN Rail Mounting |
| Installation Type | Snap-on DIN Rail |
| Colour | Grey |
CDINSW2 is widely used in:
