The CP2.5PDL is a compact and high-performance disconnect feed through terminal block designed for safe electrical isolation, organized wiring, and reliable industrial connectivity. Developed for automation systems and industrial control applications, this terminal block provides efficient circuit separation and secure electrical connections in demanding industrial environments.
Manufactured using premium-grade insulated polyamide material, the CP2.5PDL offers excellent thermal resistance, electrical insulation, and mechanical durability. Its rugged industrial construction ensures long-term performance and dependable operation in applications exposed to vibration, heat, and continuous electrical usage.
The terminal block supports 2.5 sq.mm conductor capacity, making it suitable for industrial automation systems, PLC panels, instrumentation systems, electrical control cabinets, machine wiring, and process control applications.
One of the key features of the CP2.5PDL is its disconnect functionality, which allows easy circuit isolation during maintenance, testing, and troubleshooting operations. This improves operational safety and minimizes downtime during servicing activities in industrial electrical systems.
Its compact modular structure helps optimize panel space while maintaining organized wiring layouts inside electrical cabinets and automation panels. The disconnect design simplifies maintenance procedures and allows technicians to isolate circuits without removing wiring connections.
The CP2.5PDL features a secure screw clamp connection system that provides strong conductor retention and vibration-resistant electrical connectivity. This ensures stable current transfer and minimizes the possibility of loose connections caused by industrial machine vibration or operational stress.
Its side-entry wire connection configuration allows quick conductor insertion and convenient maintenance access. The terminal block is fully compatible with standard DIN rail mounting systems, enabling fast installation and organized panel integration.
The CP2.5PDL is widely used in industries such as industrial automation, machine manufacturing, process control systems, instrumentation engineering, HVAC systems, renewable energy systems, electrical distribution systems, and factory automation projects.
Its reliable disconnect mechanism, durable insulated housing, and organized panel integration make it an ideal solution for industrial applications requiring safe circuit isolation and professional electrical connectivity.
The CP2.5PDL combines compact DIN rail design, secure electrical performance, and easy maintenance functionality, making it a dependable terminal block solution for modern industrial control systems.
| Specification | Details |
|---|---|
| Product Model | CP2.5PDL |
| Product Type | Disconnect Feed Through Terminal Block |
| Conductor Capacity | 2.5 Sq.mm |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Mounting Type | DIN Rail Mounting |
| Connection Type | Screw Clamp |
| Housing Material | Polyamide |
| Wire Entry | Side Entry |
| Disconnect Function | Yes |
| Tightening Torque | 0.4 Nm |
| Strip Length | 8 mm |
| Operating Temperature | -40°C to +105°C |
| Pollution Degree | 3 |
| Installation Type | Panel Mounted |
| Industrial Usage | Automation & Control Systems |
| HSN Code | 85389000 |
| Brand | Connectwell |
| Country of Origin | India |
The CP2.5PDL is suitable for industrial systems requiring safe circuit isolation and organized electrical connectivity.
Its disconnect functionality makes it highly suitable for systems requiring frequent maintenance and testing operations.
Allows quick electrical circuit disconnection during maintenance and troubleshooting activities.
Secure screw clamp mechanism ensures stable and vibration-resistant conductor termination.
Slim modular structure supports organized high-density panel installations.
Disconnect functionality simplifies circuit testing and servicing procedures.
Manufactured using premium insulated material for dependable long-term industrial performance.
Supports fast mounting inside automation panels and electrical cabinets.
Compact structure improves professional panel appearance and wiring organization.
The CP2.5PDL is designed for industrial systems requiring safe disconnect functionality and reliable electrical connectivity.
Professionals prefer this terminal block because of:
Its dependable industrial performance makes it suitable for automation systems, electrical control panels, and process control applications.
