The CP2.5PJL is an advanced plug-in disconnect terminal block designed for fast wiring operations, secure electrical connectivity, and simplified maintenance in industrial automation and control systems. Built for modern electrical panel applications, this terminal block combines plug-in convenience with lever-operated disconnect functionality to deliver efficient and organized industrial wiring solutions.
Manufactured using premium engineering-grade polyamide material, the CP2.5PJL offers high electrical insulation strength, superior thermal resistance, and excellent mechanical durability. Its rugged industrial construction ensures reliable long-term performance even in demanding environments exposed to vibration, heat, and continuous operational load.
The terminal block supports 2.5 sq.mm conductor capacity, making it suitable for industrial control circuits, PLC systems, instrumentation panels, automation cabinets, machine wiring systems, and process control applications.
One of the key highlights of the CP2.5PJL is its lever-operated disconnect mechanism, which allows quick circuit isolation for testing, maintenance, and troubleshooting activities. The lever design improves user convenience and reduces servicing time during industrial operations.
Its plug-in connection functionality enables faster installation and simplified wiring modifications. Technicians can easily disconnect and reconnect circuits without disturbing the complete wiring arrangement, improving maintenance efficiency and minimizing operational downtime.
The compact modular structure of the CP2.5PJL helps optimize panel installation space while maintaining clean and organized electrical layouts. This makes it ideal for high-density industrial electrical panels and automation systems requiring professional wiring management.
The terminal block features a secure screw clamp connection system that provides strong conductor holding capability and vibration-resistant electrical connectivity. This ensures stable current transfer and reduces the risk of loose wiring connections caused by machinery movement or industrial vibration.
Its side-entry wiring configuration simplifies conductor insertion and provides easy accessibility during installation and servicing procedures. The terminal block is fully compatible with standard DIN rail mounting systems, enabling fast and organized panel integration.
The CP2.5PJL is widely used in industries such as industrial automation, process control systems, manufacturing plants, instrumentation engineering, renewable energy systems, HVAC systems, machine manufacturing, and electrical control panel applications.
Its combination of lever disconnect operation, plug-in convenience, compact DIN rail design, and industrial durability makes it an ideal solution for industrial systems requiring safe and flexible electrical connectivity.
The CP2.5PJL delivers efficient circuit management, reliable electrical performance, and professional panel organization for modern industrial applications.
| Specification | Details |
|---|---|
| Product Model | CP2.5PJL |
| Product Type | Plug-In Disconnect Terminal Block |
| Conductor Capacity | 2.5 Sq.mm |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Mounting Type | DIN Rail Mounting |
| Connection Type | Screw Clamp / Plug-In |
| Disconnect Function | Lever Operated |
| Housing Material | Polyamide |
| Wire Entry | Side Entry |
| Tightening Torque | 0.4 Nm |
| Strip Length | 8 mm |
| Operating Temperature | -40°C to +105°C |
| Pollution Degree | 3 |
| Installation Type | Panel Mounted |
| Industrial Usage | Automation & Control Systems |
| HSN Code | 85389000 |
| Brand | Connectwell |
| Country of Origin | India |
The CP2.5PJL is suitable for industrial systems requiring quick disconnect functionality and organized electrical connectivity.
Its lever disconnect functionality makes it highly suitable for systems requiring regular testing and maintenance activities.
Lever-operated disconnect mechanism simplifies maintenance and troubleshooting procedures.
Plug-in design enables faster installation and easy wiring modifications.
Secure screw clamp mechanism ensures stable and vibration-resistant conductor termination.
Slim modular structure supports organized high-density electrical installations.
Quick mounting compatibility simplifies panel assembly and servicing operations.
Manufactured using premium insulated material for dependable long-term industrial reliability.
Compact design improves panel organization and structured cable routing.
The CP2.5PJL is designed for industrial systems requiring flexible disconnect functionality and reliable electrical connectivity.
Professionals prefer this terminal block because of:
Its dependable industrial performance makes it suitable for automation systems, control panels, and industrial machinery applications.
