The CP2.5PL is a compact and efficient lever disconnect feed through terminal block designed for secure electrical connectivity, easy circuit isolation, and organized panel wiring in industrial automation systems. Engineered for modern electrical control applications, this terminal block combines reliable feed through connectivity with convenient lever-operated disconnect functionality for safe maintenance and testing operations.
Manufactured using premium-grade polyamide insulated material, the CP2.5PL provides excellent electrical insulation, thermal resistance, and mechanical durability. Its rugged industrial construction ensures stable and reliable operation even in demanding environments exposed to vibration, heat, and continuous industrial usage.
The terminal block supports 2.5 sq.mm conductor capacity, making it suitable for industrial control circuits, PLC systems, instrumentation panels, electrical distribution boards, process control systems, and machine wiring applications.
One of the key highlights of the CP2.5PL is its lever-operated disconnect mechanism, which allows quick and safe circuit isolation during maintenance, troubleshooting, and testing procedures. The lever design improves servicing efficiency and minimizes downtime in industrial operations.
Its compact modular structure supports efficient panel space utilization while maintaining clean and organized electrical wiring layouts. The slim body design makes it ideal for high-density industrial control panels and automation cabinets.
The CP2.5PL features a secure screw clamp connection system that provides strong conductor retention and vibration-resistant electrical connectivity. This ensures stable current transfer and minimizes the possibility of loose electrical connections caused by industrial machinery movement or operational stress.
Its side-entry wire connection configuration allows quick conductor insertion and easy accessibility during installation and maintenance activities. The terminal block is fully compatible with standard DIN rail mounting systems, enabling fast and organized panel integration.
The CP2.5PL is widely used across industries such as industrial automation, manufacturing plants, instrumentation engineering, process control industries, renewable energy systems, HVAC systems, machine manufacturing, and factory automation projects.
Its combination of lever disconnect functionality, reliable electrical performance, compact DIN rail design, and durable industrial construction makes it an ideal solution for industrial systems requiring safe and flexible electrical connectivity.
The CP2.5PL delivers efficient circuit management, secure wire termination, and professional panel organization for modern industrial electrical applications.
| Specification | Details |
|---|---|
| Product Model | CP2.5PL |
| Product Type | Lever Disconnect Feed Through Terminal Block |
| Conductor Capacity | 2.5 Sq.mm |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Mounting Type | DIN Rail Mounting |
| Connection Type | Screw Clamp |
| Disconnect Function | Lever Operated |
| Housing Material | Polyamide |
| Wire Entry | Side Entry |
| Tightening Torque | 0.4 Nm |
| Strip Length | 8 mm |
| Operating Temperature | -40°C to +105°C |
| Pollution Degree | 3 |
| Installation Type | Panel Mounted |
| Industrial Usage | Automation & Control Systems |
| HSN Code | 85389000 |
| Brand | Connectwell |
| Country of Origin | India |
The CP2.5PL is suitable for industrial systems requiring safe disconnect functionality and organized electrical connectivity.
Its lever disconnect functionality makes it highly suitable for systems requiring regular testing and maintenance activities.
Lever-operated disconnect mechanism simplifies maintenance and troubleshooting procedures.
Secure screw clamp mechanism ensures stable and vibration-resistant conductor termination.
Slim modular structure supports organized high-density electrical installations.
Disconnect functionality simplifies circuit testing and servicing operations.
Manufactured using premium insulated material for dependable long-term industrial reliability.
Supports fast mounting inside automation panels and electrical cabinets.
Compact design improves professional panel appearance and structured cable routing.
The CP2.5PL is designed for industrial systems requiring reliable disconnect functionality and organized electrical connectivity.
Professionals prefer this terminal block because of:
Its dependable industrial performance makes it suitable for automation systems, control panels, and industrial machinery applications.
