Product Description

SB Smart CPDLG2.5 is a premium quality 2.5 sq.mm Push-In Disconnect Terminal Block designed for secure conductor termination, easy circuit isolation, and organized wiring in industrial control panels, automation systems, PLC panels, instrumentation circuits, switchgear assemblies, machine control systems, and OEM electrical applications. This advanced disconnect terminal block combines feed-through connection and disconnect functionality in one compact modular unit, making it an ideal solution for industrial electrical systems where testing, maintenance, signal isolation, and reliable wiring are essential.

The CPDLG2.5 disconnect terminal block is specially engineered to provide safe electrical continuity during normal operation and quick circuit separation whenever testing or maintenance is required. In conventional wiring systems, isolating a circuit often requires disconnecting wires manually, which can increase downtime and create maintenance risks. The SB Smart CPDLG2.5 solves this issue with its integrated disconnect mechanism, allowing fast and secure circuit interruption without disturbing adjacent wiring or affecting the complete electrical system.

One of the standout features of the SB Smart CPDLG2.5 is its advanced Push-In spring clamp connection technology, which allows tool-less wire insertion for faster and more efficient wiring. This push-in system creates a gas-tight, vibration-resistant, and maintenance-free conductor connection, ensuring reliable electrical contact over long periods. Compared to conventional screw terminals, push-in technology reduces wiring time, improves conductor holding force, and minimizes maintenance requirements in industrial applications.

Designed for 2.5 sq.mm conductor capacity, the SB Smart CPDLG2.5 supports both solid and stranded conductors, making it suitable for industrial control circuits, signal wiring, automation systems, instrumentation panels, PLC systems, OEM electrical equipment, and machine wiring applications. It offers a rated voltage of 800V and a rated current of 24A, ensuring safe and efficient electrical performance in industrial electrical systems where dependable conductor termination and circuit isolation are critical.

Manufactured using high conductivity copper alloy conductive components, the SB Smart CPDLG2.5 ensures excellent electrical conductivity, low contact resistance, and stable long-term current transfer. The conductive parts are specially designed to reduce electrical losses and minimize heat generation during operation, ensuring reliable circuit continuity and improved electrical efficiency in demanding industrial environments.

Built with a high-grade flame retardant polyamide insulated housing, the SB Smart CPDLG2.5 provides excellent electrical insulation, heat resistance, flame resistance, mechanical strength, and long service life. The insulated housing protects internal conductive components from accidental contact and environmental stress, improving operational safety in industrial electrical panels and control systems. Its grey color body makes it suitable for standard electrical wiring and organized terminal block layouts in professional installations.

The integrated disconnect slide mechanism allows electricians and maintenance engineers to quickly isolate a circuit for testing, troubleshooting, signal interruption, and maintenance operations. This feature reduces downtime, improves maintenance efficiency, and enhances operational safety in industrial electrical systems where quick circuit isolation is required.

Designed for DIN rail mounting, the SB Smart CPDLG2.5 allows fast and secure installation in standard electrical control panels and switchgear assemblies. Its compact modular construction saves panel space while improving conductor organization and wiring accessibility in crowded electrical enclosures.

With a rated surge voltage of 8KV and pollution degree 3, the SB Smart CPDLG2.5 is engineered to withstand industrial electrical disturbances, voltage fluctuations, dust, and harsh operating environments. Its rugged industrial-grade design ensures dependable long-term performance in demanding electrical applications.

SB Smart CPDLG2.5 is widely used in industrial control panels, automation systems, PLC panels, instrumentation circuits, signal isolation applications, switchgear assemblies, machine control circuits, process industries, OEM electrical systems, and industrial electrical installations where safe disconnect functionality and reliable conductor termination are essential.
