SB Smart CPDLG2.5(I.S) is a premium quality 2.5 sq.mm Push-In Disconnect Terminal Block for Intrinsically Safe (I.S.) Circuits specially designed for secure conductor termination, signal isolation, and safe circuit disconnection in hazardous area applications, instrumentation systems, PLC panels, automation equipment, process industries, and industrial control panels. This advanced disconnect terminal block combines push-in connection technology with disconnect functionality, making it an ideal solution for industrial applications where safe signal interruption, quick testing, and reliable wiring are critical.
The SB Smart CPDLG2.5(I.S) is specially developed for intrinsically safe circuits, where safe circuit segregation and signal isolation are required to protect sensitive equipment and maintain operational safety in hazardous environments. In control systems used in oil & gas plants, chemical industries, pharmaceutical units, and process automation applications, intrinsically safe circuits require dedicated terminal blocks that allow safe signal testing and disconnect functionality without disturbing the complete wiring system. This terminal block offers a dependable and professional solution for such applications.
One of the key highlights of the SB Smart CPDLG2.5(I.S) is its advanced Push-In spring clamp connection technology, which allows tool-less wire insertion for faster and more efficient installation. This push-in system creates a gas-tight, vibration-resistant, and maintenance-free conductor connection, ensuring secure wire holding and dependable long-term electrical continuity. Compared to conventional screw terminals, push-in technology reduces installation time, improves conductor safety, and minimizes maintenance requirements in industrial control systems.
Designed for 2.5 sq.mm conductor capacity, the SB Smart CPDLG2.5(I.S) supports both solid and stranded conductors, making it suitable for instrumentation loops, hazardous area signal wiring, automation panels, PLC systems, control circuits, process industries, and OEM electrical applications. It offers a rated voltage of 800V and a current carrying capacity of 24A, ensuring stable and safe electrical performance in demanding industrial applications.
Manufactured using high conductivity copper alloy conductive components, the SB Smart CPDLG2.5(I.S) ensures excellent electrical conductivity, low contact resistance, and dependable long-term current transfer. The conductive elements are specially designed to minimize electrical losses and reduce heat generation during operation, improving signal integrity and electrical efficiency in industrial instrumentation and control systems.
Built with a high-grade flame retardant polyamide insulated housing, the SB Smart CPDLG2.5(I.S) provides excellent electrical insulation, flame resistance, heat resistance, mechanical strength, and long service life. The blue color housing is specially used for intrinsically safe circuit identification, helping electricians and engineers quickly identify I.S. wiring inside hazardous area panels and instrumentation systems. This improves circuit segregation, panel organization, and maintenance convenience in industrial safety applications.
The integrated disconnect slide mechanism allows quick and safe circuit isolation for testing, troubleshooting, calibration, signal interruption, and maintenance work. This feature is especially useful in hazardous area instrumentation systems where safe signal isolation is essential for regular inspection and maintenance without disturbing adjacent circuits.
Designed for DIN rail mounting, the SB Smart CPDLG2.5(I.S) allows fast and secure installation in standard control panels, instrumentation cabinets, and industrial electrical systems. Its compact modular construction saves panel space while improving conductor accessibility and wiring organization.
With a rated surge voltage of 8KV and pollution degree 3, the SB Smart CPDLG2.5(I.S) is engineered to perform reliably in industrial environments exposed to electrical disturbances, dust, voltage fluctuations, and harsh operating conditions. Its industrial-grade construction ensures dependable long-term performance in hazardous and critical control applications.
SB Smart CPDLG2.5(I.S) is widely used in intrinsically safe circuits, hazardous area control panels, instrumentation systems, process control systems, PLC panels, automation equipment, oil & gas plants, chemical industries, pharmaceutical plants, OEM electrical systems, and industrial signal isolation applications where safe disconnect functionality and reliable conductor termination are required.
| Specification | Details |
|---|---|
| Product Name | SB Smart CPDLG2.5(I.S) |
| Model Number | CPDLG2.5(I.S) |
| Product Type | Push-In Disconnect Terminal Block (Intrinsically Safe) |
| Conductor Capacity | 2.5 sq.mm |
| Connection Type | Push-In Spring Clamp |
| Terminal Function | Disconnect / Isolation |
| Rated Voltage | 800V |
| Current Rating | 24A |
| Rated Surge Voltage | 8KV |
| Housing Material | Flame Retardant Polyamide |
| Current Bar Material | Copper Alloy |
| Wire Entry Orientation | Top Entry |
| Mounting Type | DIN 35 Rail |
| Terminal Color | Blue |
| Application | Intrinsically Safe Signal Isolation |
| Pollution Degree | 3 |
| Flame Resistance | Self Extinguishing Material |
| Stripping Length | 10 mm |
| Brand | SB Smart |
Specially made for intrinsically safe circuits where safe signal isolation is essential.
Push-in spring clamp technology enables quick and secure conductor insertion.
Built-in disconnect function allows safe circuit interruption without disturbing complete wiring.
Blue body helps quickly identify intrinsically safe wiring in control panels.
Copper alloy conductive parts ensure stable current transfer and low resistance continuity.
Push-in technology eliminates frequent retightening and improves long-term reliability.
Flame retardant insulated housing improves protection in hazardous environments.
