4 Wire Double Level Knife Disconnect Push In Spring Clamp Terminal Block, 2.5mm² – CPDLK2.5

Product Description

Industrial Disconnect Terminal for Smart Electrical Control Systems

The SB Smart CPDLK2.5 is a specially designed 2.5 sq.mm Disconnect Terminal Block built for applications where secure wire termination and quick circuit interruption are equally important. In industrial electrical systems, there are situations where engineers need to isolate a signal or control circuit for testing, maintenance, calibration, or troubleshooting. The CPDLK2.5 makes this process simple by combining feed-through electrical continuity and disconnect functionality in one compact terminal block.

Unlike ordinary terminal blocks that only provide wire-to-wire connection, the SB Smart CPDLK2.5 offers an integrated disconnect mechanism that allows operators to safely interrupt the circuit whenever required. This makes it highly useful in PLC panels, instrumentation circuits, process automation systems, machine control panels, signal wiring systems, and industrial electrical cabinets where regular circuit testing and maintenance are essential.

The terminal block is designed for 2.5 sq.mm conductor capacity, making it suitable for both solid and stranded conductors used in industrial control and signal circuits. It provides dependable electrical continuity during normal operation and allows controlled circuit isolation when maintenance or diagnostics are required. This reduces downtime and makes troubleshooting much faster and safer.

One of the standout features of the CPDLK2.5 is its knife disconnect mechanism, which enables visible and safe electrical interruption. This design is especially useful in instrumentation and control applications where technicians need to isolate a circuit without disturbing the rest of the electrical wiring. It creates a dedicated disconnect point that improves safety, maintenance efficiency, and circuit management.

For conductor connection, the terminal block uses a screw clamp termination system, providing strong conductor holding force and vibration-resistant electrical contact. In industrial environments where machines run continuously and electrical panels may experience vibration, conductor stability is critical. The secure screw clamp design minimizes loose wiring risks and ensures dependable long-term electrical contact.

The current carrying parts are manufactured using high conductivity copper alloy, which ensures efficient electrical transfer with low resistance and reduced heat generation. This improves electrical efficiency and helps maintain stable signal or current flow in control circuits and industrial wiring applications.

The body of the SB Smart CPDLK2.5 is made from flame retardant engineering polyamide, offering excellent insulation, mechanical strength, heat resistance, and protection against industrial environmental conditions. The insulated housing protects internal conductive parts and improves overall electrical safety inside control panels and automation cabinets.

Its compact DIN rail mountable design makes installation quick and professional. The modular structure helps electricians optimize panel space while maintaining organized conductor routing and easy maintenance access.

The CPDLK2.5 is widely used in industrial automation systems, PLC panels, instrumentation loops, control panels, process plants, machine wiring systems, signal isolation applications, OEM electrical assemblies, and industrial electrical installations where safe disconnect functionality is required.

With its combination of knife disconnect mechanism, secure screw clamp connection, compact modular design, reliable electrical continuity, industrial safety, and easy maintenance access, SB Smart CPDLK2.5 is an ideal disconnect terminal block for modern industrial electrical systems.
