The CPDLKFT2.5 Knife Disconnect Fuse Terminal Block is a premium industrial electrical terminal block specially designed for safe circuit isolation, fuse protection, testing accessibility, and secure conductor connectivity in industrial automation and control systems. It is widely used in PLC panels, instrumentation systems, process control panels, machine automation cabinets, signal monitoring systems, and industrial electrical installations where safe maintenance, overload protection, and testing functionality are essential.
The CPDLKFT2.5 combines multiple industrial functions into one compact terminal block by providing fuse protection, knife disconnect isolation, and test point accessibility, making it a highly efficient solution for industrial panels where maintenance engineers require fast troubleshooting, secure testing, and safe electrical protection.
Unlike standard terminal blocks, this model is specially designed for applications where circuits must be protected, isolated, and tested without disturbing field wiring connections. This makes it highly suitable for industrial control systems, process plants, instrumentation circuits, and automation applications where downtime reduction and maintenance safety are critical.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CPDLKFT2.5 is a specialized DIN rail mounted terminal block developed for industrial systems where signal and control circuits require a combination of electrical protection, disconnecting capability, and testing access.
In industrial automation systems, maintenance teams often need to:
✔ Isolate a circuit safely
✔ Replace a fuse quickly
✔ Test circuit continuity
✔ Perform troubleshooting
✔ Maintain signal integrity
The CPDLKFT2.5 provides all these functions in a single compact terminal block.
Its integrated knife disconnect mechanism allows safe interruption of electrical continuity for servicing and diagnostics, while the fuse holder protects connected circuits against overload and short-circuit conditions. The built-in test point arrangement allows technicians to measure electrical values quickly during maintenance and commissioning procedures.
This makes the terminal block highly suitable for critical industrial applications where maintenance speed, safety, and operational reliability are important.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
◆ Integrated Fuse Protection System
◆ Knife Disconnect Isolation Function
◆ Built-In Circuit Testing Accessibility
◆ Safe Maintenance Disconnecting Support
◆ Secure Screw Clamp Connection Technology
◆ Stable Signal & Current Transmission
◆ High Conductivity Copper Alloy Current Path
◆ Compact DIN Rail Mounted Design
◆ Low Contact Resistance Performance
◆ Corrosion Resistant Industrial Construction
◆ Excellent Mechanical Durability
◆ Fast Fuse Replacement Accessibility
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CPDLKFT2.5 Knife Disconnect Fuse Terminal Block is specially designed for industrial electrical systems where safe circuit interruption and maintenance access are critical for operational efficiency.
Its advanced disconnect structure helps:
✔ Safely isolate circuits
✔ Improve maintenance safety
✔ Support faster troubleshooting
✔ Reduce servicing downtime
✔ Maintain organized panel layouts
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The knife disconnect mechanism allows technicians to visually confirm circuit isolation before testing or servicing. This improves maintenance safety and helps reduce accidental electrical risks during troubleshooting procedures.
Its disconnecting structure is especially useful in instrumentation systems, PLC signal circuits, and process control applications where safe isolation of individual loops is required.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The integrated fuse protection system provides reliable protection against overload and short-circuit conditions.
Its fuse protection function helps:
◆ Protect sensitive control circuits
◆ Prevent equipment damage
◆ Reduce electrical fault risks
◆ Improve system reliability
◆ Support safe industrial operation
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
In industrial control systems, fuse protection is important for safeguarding PLC modules, instrumentation devices, control relays, and signal loops. The CPDLKFT2.5 helps protect these circuits while maintaining compact panel wiring arrangements.
The quick-access fuse replacement design reduces maintenance time and improves servicing efficiency.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The integrated testing arrangement of the CPDLKFT2.5 provides convenient access for electrical measurements during commissioning, diagnostics, and maintenance procedures.
Its testing functionality helps:
✔ Simplify circuit testing
✔ Improve troubleshooting speed
✔ Reduce maintenance complexity
✔ Support electrical diagnostics
✔ Improve technician productivity
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The testing access point eliminates the need for disturbing field wiring connections during electrical measurements, helping technicians work more safely and efficiently.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CPDLKFT2.5 is manufactured using premium flame-retardant engineering thermoplastic insulation material combined with high-conductivity copper alloy conductive components for dependable industrial operation.
This industrial-grade construction ensures:
✔ Reliable Electrical Conductivity
✔ Strong Mechanical Durability
✔ Stable Disconnect Performance
✔ Excellent Thermal Stability
✔ Long-Term Industrial Reliability
✔ Resistance Against Harsh Industrial Environments
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Its corrosion-resistant conductive structure supports stable electrical performance under vibration, humidity, heat, dust, and continuous industrial operating conditions.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CPDLKFT2.5 is specially designed for organized industrial panel wiring and efficient maintenance accessibility.
Its structured design helps:
✔ Simplify conductor insertion
✔ Improve maintenance access
✔ Reduce wiring congestion
✔ Improve troubleshooting efficiency
✔ Maintain professional panel organization
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
| Specification | Details |
|---|---|
| Product Model | CPDLKFT2.5 |
| Product Type | Knife Disconnect Fuse Terminal Block |
| Mounting Type | DIN Rail Mounting |
| Connection System | Screw Clamp Connection |
| Wire Entry Type | Horizontal Wiring Design |
| Function Type | Fuse Protection + Disconnect + Testing |
| Fuse Function | Overcurrent Protection |
| Disconnect Function | Knife Disconnect Isolation |
| Test Function | Built-In Test Point Access |
| Application Type | Control & Signal Circuits |
| Conductor Size Support | Up to 2.5 mm² |
| Housing Material | Flame Retardant Engineering Thermoplastic |
| Conductive Material | High Conductivity Copper Alloy |
| Contact Resistance | Low |
| Electrical Conductivity | Excellent |
| Mechanical Strength | High |
| Thermal Stability | Excellent |
| Corrosion Resistance | Yes |
| Maintenance Accessibility | Easy |
| Installation Type | Snap-On DIN Rail Mounting |
| Operating Environment | Industrial Applications |
| Main Application | Protection, Isolation & Testing |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Provides fuse protection, disconnecting, and testing access in one compact unit.
Protects industrial circuits from overload and short-circuit conditions.
Knife disconnect mechanism supports safe troubleshooting and servicing.
Integrated test point improves diagnostics and maintenance efficiency.
Supports clean and organized industrial control panel wiring.
Built for dependable long-term industrial operation.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✔ PLC Control Panels
✔ Instrumentation Systems
✔ Process Control Panels
✔ Industrial Automation Systems
✔ Signal Monitoring Panels
✔ Electrical Testing Applications
✔ Machine Automation Systems
✔ Control Signal Circuits
✔ Switchgear Assemblies
✔ Industrial Electrical Cabinets
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
