The CPTLG2.5 Push-In Ground Terminal Block is a high-performance 2.5 sq.mm DIN rail mounted earthing terminal block designed for safe, secure, and efficient grounding connections in electrical panels, industrial automation systems, switchgear assemblies, and commercial electrical installations. Manufactured by Connectwell, this terminal block is specifically engineered to provide reliable grounding continuity while ensuring compact installation and fast wiring through advanced push-in connection technology. It is widely used in modern electrical systems where protective earthing is essential for equipment safety and system reliability.
Ground terminal blocks play a critical role in electrical systems by providing a secure path for fault current to earth, protecting equipment and personnel from electrical hazards. The CPTLG2.5 Ground Terminal Block is designed to simplify grounding connections in control panels and switchboards by offering a compact and organized solution for conductor termination. With its 2.5 sq.mm conductor capacity, this terminal block is suitable for a wide range of industrial and commercial applications requiring dependable earthing continuity.
One of the key advantages of the CPTLG2.5 Push-In Ground Terminal Block is its push-in spring clamp technology. Unlike conventional screw clamp terminal blocks, push-in technology allows quick conductor insertion without extensive tightening procedures. This significantly reduces installation time, improves wiring efficiency, and ensures strong conductor retention. The spring-loaded contact system provides vibration-resistant and maintenance-free electrical connections, making it ideal for demanding industrial environments.
The terminal block is specially designed for protective earthing applications and features a grounding foot that establishes a secure electrical connection with the DIN rail. This ensures efficient grounding continuity throughout the panel assembly and enhances electrical safety. Its green-yellow housing color coding allows instant identification of grounding circuits, which helps electricians and maintenance teams during installation, troubleshooting, and servicing.
The CPTLG2.5 Ground Terminal Block supports a rated voltage of up to 1000V and a rated current of 24A to 30A (depending on standards), making it suitable for industrial control panels, automation systems, machine wiring, and commercial electrical assemblies. These electrical ratings ensure reliable grounding performance under normal and fault conditions, protecting connected equipment from leakage current and electrical disturbances.
Constructed with high-grade polyamide insulated housing, the terminal block offers excellent mechanical strength, electrical insulation, flame resistance, and heat resistance. The durable body protects conductors from accidental contact while maintaining safe separation inside electrical panels. This makes the CPTLG2.5 earthing terminal block highly suitable for harsh industrial operating conditions where safety and long-term durability are critical.
Another important benefit of the CPTLG2.5 Push-In Ground Terminal Block is its compact DIN rail mounting design. It can be mounted easily on DIN 35 / DIN 35-15 rails, helping panel builders optimize space inside electrical enclosures. The compact modular construction allows multiple terminal blocks to be assembled side by side, resulting in organized and professional wiring layouts. This improves panel aesthetics and makes future maintenance much easier.
The terminal block also offers excellent electrical safety with high surge voltage resistance, reliable spring pressure contact, and secure conductor termination. Since grounding systems are essential for fault current protection, using a high-quality product like CPTLG2.5 helps improve overall electrical system safety and reduces the risk of electrical failure. It is widely preferred by electricians, panel builders, OEM manufacturers, automation engineers, and industrial maintenance teams.
Whether used in control panels, switchgear systems, distribution boards, machine control cabinets, industrial automation systems, renewable energy systems, or commercial electrical installations, the CPTLG2.5 Push-In Ground Terminal Block delivers reliable earthing performance, quick installation, and long-term operational safety. Its compact size, push-in technology, and durable insulated construction make it a trusted grounding solution for modern electrical applications.
The CPTLG2.5 Push-In Ground Terminal Block is widely used in:
| Specification | Details |
|---|---|
| Model | CPTLG2.5 |
| Product Type | Push-In Ground Terminal Block |
| Wire Capacity | 2.5 sq.mm |
| Rated Voltage | 1000V |
| Rated Current | 24A – 30A |
| Connection Type | Push-In Spring Clamp |
| Mounting Type | DIN Rail Mount |
| DIN Rail Compatibility | DIN 35 / DIN 35-15 |
| Product Function | Protective Earthing / Grounding |
| Housing Material | Polyamide |
| Wire Entry Orientation | Top Entry |
| Color | Green-Yellow |
| Surge Voltage | 8KV |
| Pollution Degree | 3 |
| Operating Temperature | -40°C to +105°C |
| Application | Electrical Grounding & Earthing |
