CSB3/N3USH is a stud type hinge disconnect terminal block specially designed for industrial electrical systems where lug-based conductor termination, safe circuit isolation, and maintenance-friendly testing access are required. In electrical control panels, PLC cabinets, instrumentation systems, switchboards, industrial automation panels, and process control applications, engineers often need a terminal block that can provide both secure stud-based conductor locking and manual circuit disconnection during testing or servicing. This is especially useful in circuits where maintenance must be carried out without disturbing the complete electrical system.
Unlike standard stud type terminal blocks, the CSB3/N3USH includes a hinge disconnect mechanism, which allows the electrical path to be manually opened for testing, fault tracing, and circuit isolation. The conductor is terminated using a ring lug or fork lug over an M3 stud connection, ensuring strong mechanical wire retention even in vibration-prone industrial applications. This makes it highly suitable for industrial electrical systems where safe circuit interruption, secure lug-based wiring, and reliable electrical continuity are critical.
This terminal block is ideal for applications where circuits need to be isolated temporarily during maintenance, testing, commissioning, or troubleshooting while maintaining secure conductor termination.
The CSB3/N3USH operates as a stud type hinge disconnect terminal block, where a conductor terminated with a ring lug or fork lug is mounted over the M3 stud connection and securely tightened using a nut. A built-in hinge disconnect link allows the electrical circuit to be manually opened or closed whenever required.
Its working design provides:
This makes the terminal block highly suitable for industrial applications where circuit interruption and secure conductor retention are equally important.
The CSB3/N3USH improves electrical safety by combining secure stud termination and safe disconnect capability in one terminal block.
Safety advantages include:
This helps technicians isolate circuits safely without removing conductors.
The CSB3/N3USH provides several maintenance advantages.
Benefits include:
This makes it highly suitable for industrial electrical testing systems.
The CSB3/N3USH is manufactured using flame-retardant polyamide insulated housing with industrial-grade conductive stud and hinge disconnect hardware, designed for demanding industrial electrical applications.
Construction advantages include:
Its rugged construction ensures dependable electrical performance in industrial heavy-duty wiring applications.
Using CSB3/N3USH improves panel layout by combining secure lug-based termination and disconnect functionality in one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CSB3/N3USH |
| Product Type | Stud Type Hinge Disconnect Terminal Block |
| Rated Voltage | 1000 V / 1100 V |
| Rated Current | 41 A |
| Conductor Capacity | 0.5 – 6 mm² |
| AWG Range | 22 – 8 AWG |
| Stud Size | M3 |
| Connection System | Stud Connection |
| Disconnect Mechanism | Hinge Disconnect |
| Operation | Screwdriver / Nut Driver |
| Tightening Torque | 0.5 Nm |
| Mounting Style | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Length | 49 mm |
| Thickness | 9 mm |
| Electrical Function | Feed Through / Disconnect |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Instrumentation, Switchboards |
Built-in hinge disconnect supports maintenance and testing.
Strong M3 stud locking for heavy-duty conductor termination.
Supports fault tracing and commissioning.
Stable industrial electrical performance.
Ideal for demanding industrial applications.
Built for long-term industrial use.
Improves safe and organized panel layouts.
CSB3/N3USH is widely used in:
