CSCP2.5T is a compact and efficient 2.5 sq.mm spring clamp panel mount terminal block designed for secure conductor termination and space-saving electrical wiring in industrial and commercial applications. Built for direct panel and surface mounting, this terminal block provides reliable electrical connectivity while supporting modular assembly for customized multi-pole terminal configurations. It is widely used in control panels, machine wiring, automation systems, electrical cabinets, instrumentation panels, OEM equipment, and compact electrical installations.
This terminal block is engineered specifically for applications where installation space is limited and organized conductor management is essential. Its compact body design allows multiple terminals to be stacked together to create customized terminal assemblies, helping improve panel layout and maximize enclosure utilization.
CSCP2.5T uses spring clamp connection technology, which provides secure and maintenance-free conductor termination. Unlike traditional screw-type terminals that may require periodic retightening, the internal spring mechanism maintains constant clamping pressure and supports long-term electrical reliability even under vibration and temperature variations.
The terminal operates using a screwdriver-actuated spring mechanism. During installation, the clamp is opened using a suitable tool, the conductor is inserted, and once the tool is released, the internal spring securely grips the conductor to establish a stable electrical connection. This installation process helps reduce wiring time and improves consistency during panel assembly.
Its top-entry conductor orientation provides convenient wiring access and supports cleaner cable routing inside compact enclosures. Top-entry insertion also improves accessibility during maintenance and troubleshooting activities.
Unlike DIN rail terminal systems, CSCP2.5T is designed for panel or surface mounting, making it suitable for applications where direct mounting is preferred or where DIN rail installation is not practical. Multiple terminals can be stacked and fixed using mounting end plates to create organized multi-terminal assemblies.
The terminal block supports cross connection using insulated external shorting links, enabling efficient commoning and simplified electrical distribution across adjacent terminal positions. This flexibility supports modular wiring practices and structured panel construction.
With a rated voltage of 800V and rated current of 24A, CSCP2.5T delivers dependable electrical performance across industrial control and distribution applications. Ratings are based on copper conductor usage under standard installation conditions.
The terminal supports conductor sizes from 0.2 sq.mm to 2.5 sq.mm stranded conductors and up to 4 sq.mm solid conductors, providing flexibility across multiple wiring requirements. Support for ferrules and dual conductor termination further improves installation versatility.
Manufactured using polyamide housing material, the terminal block offers strong insulation performance, dimensional stability, and mechanical durability suitable for demanding industrial operating environments. It also features 8 kV surge resistance and pollution degree 3 protection characteristics.
Its compact dimensions — 5 mm width, 35 mm length, and 27.3 mm height — make CSCP2.5T an ideal solution for high-density wiring applications where enclosure space optimization is important.
CSCP2.5T is commonly used in industrial control panels, electrical cabinets, automation systems, machine control installations, instrumentation panels, process industries, OEM equipment manufacturing, and modular electrical assemblies where secure spring-clamp connectivity and compact mounting solutions are required.
| Specification | Details |
|---|---|
| Product Code | CSCP2.5T |
| Product Type | Panel Mount Spring Clamp Terminal Block |
| Terminal Capacity | 2.5 sq.mm |
| Product Function | Feed Through |
| Connection Technology | Spring Clamp |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Housing Material | Polyamide |
| Mounting Type | Panel / Surface Mount |
| Wire Entry Orientation | Top Entry |
| Operation | Screwdriver Actuated |
| Stranded Conductor Range | 0.2–2.5 sq.mm |
| Solid Conductor Range | 0.2–4 sq.mm |
| AWG Range | 22–14 AWG |
| Dual Conductor Support | Up to 1.5 sq.mm |
| Stripping Length | 11 mm |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 5 mm |
| Length | 35 mm |
| Height | 27.3 mm |
| Standard Pack | 100 Pieces |
Technical specifications compiled from published technical references.
CSCP2.5T is suitable for:
Supports high-density panel layouts.
Spring clamp mechanism simplifies conductor insertion.
Continuous spring pressure eliminates retightening.
Maintains stable performance under industrial conditions.
Supports customized multi-pole terminal assemblies.
