The CTS35UNAR is a heavy-duty feed through terminal block designed for secure high-current electrical connections in industrial automation and power distribution systems. This industrial-grade terminal block is widely used in PLC panels, switchgear assemblies, motor control systems, electrical control cabinets, machine automation panels, and industrial distribution applications where reliable conductor termination is essential.
Built for DIN rail mounting systems, the CTS35UNAR supports large conductor sizes up to 35 sq.mm and delivers dependable electrical performance in demanding industrial environments. Its Allen screw clamp connection technology provides strong conductor holding force, vibration-resistant termination, and long-term operational reliability.
Manufactured using industrial-grade polyamide insulation material and high-conductivity metallic components, the CTS35UNAR offers excellent electrical insulation, thermal resistance, and mechanical durability for continuous industrial operation. The red housing color supports easy circuit identification and organized wiring management inside control panels.
Its compact modular design enables efficient panel space utilization while maintaining clean and maintenance-friendly electrical installations.
The CTS35UNAR feed through terminal block is specially engineered for industrial electrical systems involving high-current circuits and large conductor sizes. The feed through configuration enables direct conductor continuity between connected wires, ensuring efficient power transmission and organized electrical distribution.
Its Allen screw operated clamp mechanism provides strong and secure conductor gripping, minimizing the possibility of loose connections caused by vibration, thermal expansion, or continuous industrial operation. This ensures stable and safe electrical performance in harsh operating environments.
Compatible with DIN 32, DIN 35, and DIN 35-15 mounting rails, the terminal block offers flexible installation options across various industrial control panel configurations. The flexible mounting foot allows easy installation and removal from DIN rails using an Allen key or screwdriver.
The CTS35UNAR is extensively used in industrial machinery, electrical distribution systems, process automation equipment, renewable energy installations, factory automation systems, and OEM electrical assemblies.
| Specification | Details |
|---|---|
| Model Number | CTS35UNAR |
| Product Type | Feed Through Terminal Block |
| Connection Technology | Allen Screw Clamp |
| Mounting Type | DIN Rail Mounting |
| Rated Voltage | 1000 V |
| Rated Current | 125 A |
| Rated Surge Voltage | 8 kV |
| Tightening Torque | 2.5 Nm |
| Wire Size Range | 4 sq.mm to 35 sq.mm |
| AWG Range | 12 AWG to 2 AWG |
| Housing Material | Polyamide |
| Wire Entry Orientation | Side Entry |
| Screw Size | M6 |
| Mounting Compatibility | DIN 32 / DIN 35 / DIN 35-15 Rail |
| Width | 16 mm |
| Length | 50.5 mm |
| Pollution Degree | 3 |
| Color | Red |
| Operation | Allen Key Operated |
| Industrial Usage | Automation & Power Distribution |
The CTS35UNAR terminal block is widely used in industrial electrical systems requiring secure high-current conductor connections and organized electrical distribution.
Its heavy-duty construction makes it ideal for industrial environments involving continuous electrical operation and large conductor sizes.
The CTS35UNAR provides stable and secure electrical connections for industrial power applications up to 125 A.
Its industrial-grade construction ensures long-term resistance against vibration, heat, and mechanical stress.
The Allen screw clamp system delivers dependable conductor gripping and minimizes connection failures.
The high-quality insulation material helps prevent electrical leakage and overheating.
Its modular DIN rail mounted design supports clean and professional electrical panel layouts.
The flexible mounting foot and Allen screw mechanism simplify installation and maintenance procedures.
Designed for industrial environments, the terminal block offers reliable long-term performance with minimal maintenance.
Feed through terminal blocks are essential components in industrial electrical systems because they provide safe and organized conductor termination for power and control circuits. The CTS35UNAR is especially suitable for heavy-duty applications involving high current transmission and large conductor sizes.
In industrial automation systems, reliable electrical connections help prevent voltage drops, overheating, and equipment failures. The CTS35UNAR ensures dependable power distribution while improving wiring organization and maintenance accessibility.
Its compatibility with multiple DIN rail systems also supports flexible integration into modern industrial control systems and automation panels.
The CTS35UNAR offers an excellent combination of high electrical performance, industrial durability, compact design, and installation flexibility. Its robust Allen screw clamp mechanism ensures secure conductor holding and efficient current transfer for demanding industrial applications.
The terminal block is ideal for automation systems, electrical switchboards, industrial machinery, motor control panels, and power distribution systems requiring reliable heavy-duty electrical connectivity.
Its strong insulation properties, low-maintenance design, and long operational life make it a preferred choice for electrical engineers, industrial electricians, automation professionals, and OEM panel manufacturers.
