CX10Y is a 10 sq.mm feed-through spring clamp terminal block in yellow color, designed for fast, secure, and organized industrial electrical wiring applications. It is specially developed for control panels, switchboards, PLC systems, automation cabinets, and electrical distribution boards where dependable conductor connection and easy circuit identification are essential.
This terminal block uses a spring clamp connection technology, which provides a pressure-based wire holding mechanism for secure electrical contact. Unlike conventional screw-based terminals, the spring clamp system reduces installation time, minimizes maintenance requirements, and provides stable conductor holding even in environments exposed to vibration or continuous industrial operation.
The yellow housing color gives additional functional value by supporting special circuit identification, warning line separation, dedicated control wiring, or phase distinction inside electrical panels. In complex industrial installations, color-coded terminals help technicians identify circuits quickly, reduce maintenance errors, and improve servicing efficiency.
The CX10Y is designed for top-entry conductor insertion, making panel wiring easier and more accessible in compact electrical cabinets. Its slim DIN rail compatible body allows organized and space-saving installation while maintaining strong electrical continuity and safe conductor insulation.
Manufactured from high-strength flame-retardant engineering polyamide, the CX10Y offers excellent insulation performance, thermal resistance, and mechanical durability. Its vibration-proof spring clamp design makes it suitable for industrial machinery, OEM electrical assemblies, process automation systems, instrumentation panels, and heavy-duty control panel applications.
Because of its fast wiring capability, secure spring clamp technology, compact design, and bright yellow identification housing, the CX10Y is widely used by industrial electricians, panel manufacturers, automation engineers, and maintenance professionals for professional electrical panel wiring solutions.
| Parameter | Specification |
|---|---|
| Product Code | CX10Y |
| Product Type | Feed Through Spring Clamp Terminal Block |
| Color | Yellow |
| Rated Voltage | 1000 V |
| Rated Current | 57 A |
| Conductor Capacity | 0.2 – 10 mm² |
| AWG Range | 24 – 6 AWG |
| Connection System | Spring Clamp |
| Mounting Style | DIN 35 / DIN 35-15 Rail |
| Wire Entry | Top Entry |
| Operation | Screwdriver Operated |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 10 mm |
| Length | 71.7 mm |
| Stripping Length | 18 mm |
| Electrical Function | Feed Through Terminal Block |
CX10Y is commonly used in:
Spring clamp technology reduces wiring time compared to traditional screw terminals.
Yellow housing makes special circuits easy to identify.
Provides secure conductor holding even in vibration-prone environments.
Slim DIN rail body supports organized wiring in limited space.
Spring pressure connection minimizes wire loosening issues.
Built for long-term use in demanding industrial applications.
