CX2.5/3 is a three-level feed through spring clamp terminal block designed for industrial electrical systems where multiple conductor connections, compact DIN rail installation, and organized multi-circuit wiring are required within limited panel space. In modern control panels, PLC cabinets, industrial automation systems, machine control panels, and switchboards, engineers often need to terminate several conductors in a small section of the DIN rail. Using standard single-level terminals in such applications increases wiring congestion and consumes more panel space.
The CX2.5/3 solves this problem by integrating three independent feed through conductor connection levels in one compact terminal body, allowing multiple circuits to be connected vertically instead of using separate individual terminals. This helps save DIN rail space, improves panel compactness, and supports better wiring organization.
Its spring clamp conductor connection technology offers fast conductor insertion, vibration-resistant wire holding, and maintenance-free electrical contact, making it highly suitable for demanding industrial environments.
This terminal block is ideal for applications where high-density panel wiring, secure conductor locking, and efficient multi-circuit electrical distribution are essential.
The CX2.5/3 operates as a three-level spring clamp feed through terminal block, where conductors are connected through three separate electrical levels integrated inside one terminal body.
Its working design provides:
The spring clamp connection mechanism uses pressure-based conductor locking, ensuring secure wire holding and reducing the possibility of conductor loosening due to vibration or long-term industrial use.
This creates a compact and efficient multi-circuit wiring solution.
The CX2.5/3 improves electrical safety by organizing multiple circuits in one compact and structured terminal arrangement.
Safety advantages include:
Spring clamp technology helps improve conductor reliability in industrial electrical systems.
The three-level design provides several industrial wiring benefits.
Benefits include:
This makes the CX2.5/3 ideal for compact industrial electrical cabinets.
The CX2.5/3 is manufactured using flame-retardant engineering polyamide insulation with precision spring clamp conductive hardware, designed for industrial electrical environments.
Construction advantages include:
Its rugged construction ensures dependable industrial electrical performance.
Using CX2.5/3 improves panel layout by combining three conductor circuits into one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CX2.5/3 |
| Product Type | Three-Level Feed Through Spring Clamp Terminal Block |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Conductor Capacity | 0.2 – 2.5 mm² |
| AWG Range | 24 – 12 AWG |
| Connection System | Spring Clamp |
| Number of Levels | 3 Level |
| Mounting Style | DIN 35 / DIN 35-15 Rail |
| Wire Entry | Top Entry |
| Operation | Screwdriver Operated |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Feed Through Multi-Level Terminal |
| Installation Type | Spring Pressure Connection |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Automation Systems, Switchboards |
Supports compact high-density industrial wiring.
Spring clamp technology reduces installation time.
Reduces DIN rail usage in electrical cabinets.
Spring pressure ensures reliable wire locking.
Suitable for industrial operating conditions.
Built for demanding industrial applications.
Improves clean and structured wiring layouts.
CX2.5/3 is widely used in:
