The CX2.5/4BK Feed Through Terminal Block is a compact and reliable electrical connection component designed for secure wire termination in industrial, commercial, and electrical panel applications. It is specially engineered to provide safe electrical continuity between incoming and outgoing conductors while maintaining organized panel wiring and dependable long-term performance. This feed through terminal block is widely used in control panels, switchgear systems, distribution boards, machine wiring, automation systems, and industrial electrical installations where safe and efficient wire management is essential.
Modern electrical panels require terminal blocks that not only provide secure electrical connections but also improve cable organization and simplify maintenance. The CX2.5/4BK Feed Through Terminal Block is designed to meet these requirements by offering a strong and compact connection point for conductors. Its feed through terminal design allows wires to be connected safely from one side to the other, ensuring stable electrical continuity and making wiring systems cleaner and more organized.
One of the major advantages of the CX2.5/4BK Terminal Block is its ability to support reliable wire termination in compact panel spaces. In industrial control panels and machine wiring systems, multiple conductors often need to be connected in an organized manner without creating cable clutter. This terminal block helps electricians and panel builders create structured wiring layouts while reducing installation complexity and improving future maintenance convenience.
The CX2.5/4BK is designed for 2.5 sq.mm conductor capacity, making it suitable for low and medium power control circuits where secure wire termination and safe electrical transfer are important. It supports a rated voltage of 800V and a rated current of 24A, providing dependable electrical performance for industrial and commercial wiring systems. Its strong current carrying capability makes it suitable for control wiring, signal circuits, machine control systems, and electrical distribution applications.
A key feature of this terminal block is its feed through connection design, which provides direct electrical continuity between connected conductors. This helps simplify panel wiring and creates efficient conductor routing in control panels and electrical enclosures. The secure screw clamp mechanism ensures tight conductor fastening, reducing the risk of loose wiring, overheating, voltage drop, or electrical faults during operation.
The body of the CX2.5/4BK Feed Through Terminal Block is manufactured using high-quality polyamide insulated housing, offering excellent electrical insulation, heat resistance, impact strength, and long service life. This durable insulated housing protects internal conductive parts from accidental contact and improves safety during electrical operation. Polyamide construction also ensures reliable performance in industrial environments exposed to mechanical stress and temperature variations.
Its side-entry wire connection orientation allows convenient cable insertion and organized wire routing inside electrical panels. This feature helps reduce wiring complexity and improves cable management, especially in compact control panel installations. The secure screw clamp system provides vibration-resistant conductor retention and ensures stable electrical contact during long-term use.
The CX2.5/4BK is designed for DIN rail mounting, making installation fast, easy, and compatible with standard industrial electrical panel systems. DIN rail mounting improves component organization, reduces installation time, and allows easy replacement or maintenance when required. This mounting flexibility makes the terminal block suitable for professional electrical panel building applications.
Electrical safety is an important requirement in any wiring system, and the CX2.5/4BK is designed to deliver reliable protection. It features strong insulation properties, secure conductor fastening, and dependable electrical continuity, helping improve wiring safety and long-term panel reliability in industrial applications.
The CX2.5/4BK Feed Through Terminal Block is commonly used in:
Its compact design, reliable feed through connection, secure screw clamp termination, and durable insulated housing make it an ideal choice for professional electrical installations.
| Specification | Details |
|---|---|
| Model Number | CX2.5/4BK |
| Product Type | Feed Through Terminal Block |
| Rated Voltage | 800V |
| Rated Current | 24A |
| Cable Size | 0.2 – 4 sq.mm |
| Nominal Cross Section | 2.5 sq.mm |
| Connection Type | Screw Clamp |
| Terminal Type | Feed Through |
| Housing Material | Polyamide |
| Color | Black |
| Mounting Type | DIN Rail Mounting |
| DIN Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Wire Entry Orientation | Side Entry |
| Tightening Torque | 0.5 Nm |
| Rated Surge Voltage | 8KV |
| Pollution Degree | 3 |
| Length | 47.5 mm |
| Width | 6.2 mm |
| Applications | Control Panels, Switchgear, Distribution Boards |
✅ Compact space-saving design
✅ Reliable feed through wire connection
✅ Supports 24A current carrying capacity
✅ Suitable for 800V rated voltage
✅ Secure screw clamp conductor fastening
✅ Strong insulated polyamide housing
✅ Easy DIN rail mounting installation
✅ Side-entry wiring for convenient cable management
✅ Reduces wiring complexity in panels
✅ Suitable for industrial and commercial applications
✅ Reliable electrical safety and performance
✅ Long-lasting durable construction
