CX2.5PN/10 is a 10-pole pluggable spring clamp terminal block designed for fast, secure, and maintenance-free electrical connections in industrial wiring systems. It is specially used in control panels, PLC systems, switchgear assemblies, automation cabinets, machine wiring, instrumentation circuits, and modular electrical installations where quick plug-in connection and reliable conductor retention are essential. The compact 10-pole multi-circuit design allows multiple connections in a single plug assembly, helping save panel space and improve organized wiring.
One of the biggest advantages of CX2.5PN/10 is its advanced spring clamp connection technology, which provides strong and consistent clamping force without screw tightening. This ensures secure wire holding, stable electrical continuity, and vibration-resistant performance, making it ideal for demanding industrial environments where loose wiring can cause faults or downtime.
The pluggable modular design allows complete wiring sections to be connected or removed quickly without disturbing individual conductors. This feature makes installation faster, maintenance easier, and machine servicing more efficient, helping reduce downtime in industrial electrical systems.
✅ 10 Pole Compact Design – Multiple circuits in one connector for space-saving panel wiring
✅ Spring Clamp Technology – Secure wire holding without screw loosening problems
✅ Quick Plug & Unplug System – Fast maintenance and easy modular connection
✅ Vibration Resistant Connection – Ideal for machine panels and industrial environments
✅ Maintenance-Free Operation – No periodic retightening required
✅ Low Contact Resistance – Stable current flow and reliable electrical continuity
✅ Time Saving Installation – Faster wiring compared to conventional terminal connectors
✅ Strong Mechanical Construction – Durable insulated housing for industrial use
Manufactured with high-quality engineering-grade insulating material, CX2.5PN/10 provides excellent electrical insulation, strong mechanical durability, and long service life in industrial applications. Its side-entry wiring design allows easy conductor insertion and better accessibility inside compact electrical panels.
CX2.5PN/10 is used in industrial and electrical systems where quick plug-in connection, secure wire termination, compact multi-pole wiring, and easy maintenance are required. It is widely used in automation panels, PLC wiring, machine controls, instrumentation circuits, HVAC controls, OEM electrical equipment, robotics, and switchgear panels where reliable electrical continuity and fast servicing are important.
✔ Reduces installation time
✔ Improves maintenance efficiency
✔ Supports modular wiring systems
✔ Provides secure vibration-proof connection
✔ Helps organize high-density panel wiring
✔ Reduces downtime during servicing
CX2.5PN/10 works on a spring pressure clamping mechanism combined with a pluggable modular structure. Conductors are inserted into the wire entry point and securely held by spring force, ensuring strong electrical contact and reliable conductor retention. A screwdriver-actuated release mechanism allows easy wire insertion and removal.
After wiring, the plug assembly can be inserted or removed from the mating base quickly, without disconnecting each wire individually. This working principle supports fast installation, modular maintenance, easy replacement, and secure electrical signal or power transfer.
⭐ 10 Pole Pluggable Connector Design
⭐ Spring Clamp Wire Connection
⭐ Quick Plug-In / Plug-Out Operation
⭐ Maintenance-Free Connection System
⭐ Vibration Resistant Electrical Contact
⭐ Secure Wire Retention Technology
⭐ Compact Space Saving Construction
⭐ Low Contact Resistance Performance
⭐ Fast Panel Installation
⭐ Industrial Grade Insulated Housing
CX2.5PN/10 is designed to improve electrical safety, wiring identification, and secure circuit management inside industrial panels. Its insulated housing protects against accidental contact with live conductors, improving operator safety during installation and maintenance.
🔹 Secure conductor locking system
🔹 Reduced loose wire risk
🔹 Improved electrical safety
🔹 Protection against accidental contact
🔹 Organized circuit connection points
🔹 Reduced overheating chances
The yellow-green identification colour is specially used for protective earth (PE) and grounding circuit recognition in industrial electrical systems.
✔ Quick grounding circuit identification
✔ Reduces wiring mistakes
✔ Improves technician safety
✔ Supports standard electrical coding
✔ Faster troubleshooting and maintenance
✔ Better panel wiring organization
CX2.5PN/10 is manufactured using high-strength engineering-grade polyamide insulated housing designed for industrial use. It provides excellent mechanical durability, heat resistance, electrical insulation, and long-term reliability.
✅ Durable industrial-grade housing
✅ High insulation performance
✅ Heat resistant material
✅ Strong spring clamp mechanism
✅ Repeated plug-in durability
✅ Long service life design
The compact 10-pole pluggable design of CX2.5PN/10 helps improve panel wiring organization by allowing multiple circuits to be connected in a neat and modular way.
✔ Saves panel space
✔ Reduces wiring clutter
✔ Improves cable routing
✔ Faster troubleshooting
✔ Supports modular panel design
✔ Cleaner and professional panel layout
✔ Quick replacement during maintenance
| Parameter | Specification |
|---|---|
| Product Code | CX2.5PN/10 |
| Product Type | Pluggable Spring Clamp Terminal Block |
| Configuration | Plug Type Feed Through Connector |
| Number of Poles | 10 Pole |
| Connection Technology | Spring Clamp Connection |
| Wire Entry Orientation | Side Entry |
| Operation Method | Screwdriver Actuated |
| Housing Material | Polyamide (PA) |
| Housing Colour | Grey |
| Flammability Class | UL94 V-0 |
| Pollution Degree | 3 |
| Parameter | Specification |
|---|---|
| Rated Voltage (IEC) | 500 V |
| Rated Voltage (UL / CSA) | 300 V |
| Rated Current (IEC) | 24 A |
| Rated Current (UL / CSA) | 20 A |
| Rated Surge Voltage | 8 kV |
| Contact Resistance | Low Resistance Contact System |
| Insulation Performance | High Industrial Grade Insulation |
| Parameter | Specification |
|---|---|
| Stranded Conductor Range | 0.2 mm² – 2.5 mm² |
| Solid Conductor Range | 0.2 mm² – 4 mm² |
| AWG Range | 24 AWG – 12 AWG |
| Conductor with Ferrule | 0.2 mm² – 2.5 mm² |
| Twin Ferrule Range | 0.2 mm² – 1.0 mm² |
| Two Conductors Same Cross Section | 0.2 mm² – 1.5 mm² |
| Wire Stripping Length | 10 mm |
| Parameter | Specification |
|---|---|
| Width / Thickness | 5 mm |
| Height | 40 mm |
| Length | 18 mm |
| Construction Type | Compact Modular Plug Design |
| Contact System | Spring Pressure Clamp |
| Wire Retention | Secure Vibration Resistant Holding |
| Mechanical Strength | Industrial Grade Durable Construction |
| Parameter | Specification |
|---|---|
| Plug-In / Plug-Out Capability | Yes |
| Maintenance-Free Operation | Yes |
| Vibration Resistant Connection | Yes |
| Secure Conductor Retention | Yes |
| Low Contact Resistance | Yes |
| Fast Installation Support | Yes |
| Modular Wiring Compatibility | Yes |
| Space Saving Panel Design | Yes |
| Application Area | Suitability |
|---|---|
| PLC Panels | Yes |
| Control Panels | Yes |
| Industrial Automation Systems | Yes |
| Switchgear Assemblies | Yes |
| Machine Wiring Systems | Yes |
| Instrumentation Circuits | Yes |
| HVAC Electrical Panels | Yes |
| OEM Electrical Equipment | Yes |
| Robotics & Process Control Systems | Yes |
| Parameter | Specification |
|---|---|
| Standard Pack Quantity | 25 Pieces |
