CX2.5PN/6 is a high-performance 6 Pole Pluggable Spring Clamp Terminal Block Plug designed for safe, reliable, and efficient electrical wiring in industrial control panels, switchgear systems, automation equipment, and machine wiring applications. Manufactured for use in demanding electrical environments, this terminal block plug offers secure wire termination with advanced spring clamp connection technology, ensuring vibration-resistant and maintenance-free performance.
This pluggable terminal block is specially designed for applications where quick disconnection and reconnection of wiring is required. The 6-pole stacked plug design allows multiple connections in a compact format, making it ideal for organized wiring systems, wire harness assemblies, industrial machinery, PLC panels, power distribution systems, and electrical cabinets.
The spring clamp connection technology provides a secure and gas-tight electrical connection without requiring periodic tightening, unlike traditional screw terminal systems. This feature reduces maintenance costs and ensures long-term connection reliability even in high-vibration industrial environments.
CX2.5PN/6 supports conductor sizes up to 2.5 mm² stranded wire and offers excellent current carrying capability up to 24A, making it suitable for signal, control, and power distribution applications. With a rated voltage of 500V (IEC), this terminal plug provides safe and efficient electrical performance in industrial circuits.
Its compact 6 pole modular design allows users to create organized multi-wire harness connections while reducing wiring complexity. The stackable construction makes installation flexible and saves valuable panel space in dense electrical assemblies.
Designed with durable engineering-grade insulating material, the terminal block offers excellent mechanical strength, heat resistance, and electrical insulation properties. The rated surge voltage of 8kV ensures better protection against transient voltage spikes, improving safety in industrial applications.
The top wire entry orientation simplifies wiring access and installation, while screwdriver-operated spring clamp mechanism ensures quick conductor insertion and removal. This makes the product suitable for panel builders, automation integrators, machine manufacturers, and electrical contractors.
CX2.5PN/6 is widely used in:
Its maintenance-free, vibration-proof, and space-saving design makes it a preferred solution for modern industrial wiring requirements.
| Specification | Details |
|---|---|
| Model Number | CX2.5PN/6 |
| Product Type | Feed-through Terminal Block Plug |
| Connection Technology | Spring Clamp |
| Number of Poles | 6 Pole |
| Rated Voltage (IEC) | 500 V |
| Rated Current (IEC) | 24 A |
| Rated Voltage (UL/CSA) | 300 V |
| Rated Current (UL/CSA) | 20 A |
| Conductor Cross Section (Solid) | 0.2 – 4 mm² |
| Conductor Cross Section (Stranded) | 0.2 – 2.5 mm² |
| Ferrule Wire Capacity | 0.2 – 2.5 mm² |
| Twin Ferrule Capacity | 0.2 – 1.5 mm² |
| AWG Range | 24 – 12 AWG |
| Wire Stripping Length | 10 mm |
| Wire Entry Orientation | Top |
| Operation Type | Screwdriver Operated |
| Rated Surge Voltage | 8 kV |
| Short-Time Withstand Current | 0.3 kA |
| Overvoltage Category | III |
| Pollution Degree | 3 |
| Internally Shorted | No |
| Ground Feet | No |
| Colour | Grey |
| Operating Temperature | -40°C to +105°C |
| Mounting Style | Pluggable |
| Application | Control Panels, PLC, Automation, Switchgear |
CX2.5PN/6 is suitable for:
