CX2.5PN/8 is a high-performance 8 Pole Pluggable Spring Clamp Terminal Block Plug designed for safe, compact, and efficient electrical connections in industrial control panels, automation systems, switchgear assemblies, and machine wiring applications. It is specially engineered for applications where quick plug-in and unplug wiring connections are required, ensuring faster installation, reduced maintenance, and reliable electrical continuity.
This terminal block plug features advanced spring clamp connection technology, which provides a secure, vibration-resistant, and maintenance-free electrical connection. Unlike conventional screw-type terminals, the spring clamp mechanism automatically maintains contact pressure, ensuring stable performance even in high-vibration industrial environments. This reduces the need for periodic tightening and improves long-term reliability in demanding electrical applications.
The 8 pole pluggable design allows multiple conductor connections in one compact unit, helping panel builders and electrical engineers create organized and space-saving wiring systems. Its modular pluggable construction enables quick disconnection and reconnection of circuits during maintenance, testing, or equipment replacement, making it highly suitable for modern industrial automation and control systems.
CX2.5PN/8 supports conductor sizes up to 2.5 mm² stranded wire and delivers a rated current of 24A with a rated voltage of 500V (IEC), making it ideal for signal, control, and power distribution applications. The terminal plug is also designed to meet international electrical standards with UL/CSA ratings of 300V and 20A, ensuring safe use in global industrial applications.
The terminal block features top wire entry orientation, allowing easy conductor insertion and neat cable routing inside control panels and electrical cabinets. The screwdriver-operated spring clamp mechanism ensures quick installation and easy wire release, reducing installation time and improving maintenance convenience.
Manufactured using high-quality Polyamide insulating material, CX2.5PN/8 offers excellent electrical insulation, flame resistance, mechanical strength, and long service life. The terminal block also provides a rated surge voltage of 8kV, offering additional protection against transient voltage spikes in industrial electrical systems.
Its compact pluggable design, secure spring clamp technology, and maintenance-free operation make CX2.5PN/8 an ideal solution for industrial control panels, PLC systems, machine wiring, switchgear, instrumentation panels, wire harness assemblies, and OEM electrical equipment.
CX2.5PN/8 is widely preferred by panel builders, automation engineers, machine manufacturers, and industrial electricians for its reliable performance, compact modular design, and safe electrical connection technology.
| Specification | Details |
|---|---|
| Model Number | CX2.5PN/8 |
| Product Type | Feed-through Terminal Block Plug |
| Connection Technology | Spring Clamp |
| Number of Poles | 8 Pole |
| Rated Voltage (IEC) | 500 V |
| Rated Current (IEC) | 24 A |
| Rated Voltage (UL/CSA) | 300 V |
| Rated Current (UL/CSA) | 20 A |
| Conductor Cross Section (Solid) | 0.2 – 4 mm² |
| Conductor Cross Section (Stranded) | 0.2 – 2.5 mm² |
| Ferrule Wire Capacity | 0.2 – 2.5 mm² |
| Twin Ferrule Capacity | 0.2 – 1.5 mm² |
| AWG Range | 24 – 12 AWG |
| Wire Stripping Length | 10 mm |
| Wire Entry Orientation | Top |
| Operation Type | Screwdriver Operated |
| Rated Surge Voltage | 8 kV |
| Short-Time Withstand Current | 0.3 kA |
| Overvoltage Category | III |
| Pollution Degree | 3 |
| Internally Shorted | No |
| Ground Feet | No |
| Housing Material | Polyamide |
| Colour | Grey |
| Operating Temperature | -40°C to +105°C |
| Mounting Style | Pluggable |
CX2.5PN/8 is widely used in:
