The CXF4L6-60V is a high-performance spring clamp fuse terminal block designed for industrial automation systems, electrical control panels, PLC panels, switchgear assemblies, and power distribution applications. Built for reliable electrical protection and secure connectivity, this terminal block combines compact design, advanced spring clamp technology, and integrated fuse indication for efficient industrial operations.
This industrial-grade fuse terminal block supports 5x20 mm glass fuses and includes an LED indication feature that helps maintenance engineers quickly identify blown fuses, reducing troubleshooting time and minimizing system downtime. The spring clamp connection mechanism provides vibration-resistant and maintenance-free wiring, making it ideal for demanding industrial environments with continuous operation.
The compact 6 mm width design allows maximum space optimization inside electrical cabinets and control panels. It supports conductor sizes up to 4 mm² and is compatible with DIN 35 and DIN 35-15 mounting rails for easy and secure installation.
Manufactured using premium Polyamide 66 insulation material, the CXF4L6-60V offers excellent thermal resistance, electrical insulation, flame resistance, and long-term durability. Its top-entry wiring structure ensures easy cable management and simplified installation in densely populated panel assemblies.
This fuse terminal block is widely used in:
The integrated LED indication operates within a 6–60V AC/DC range, allowing quick visual monitoring of fuse conditions. Its reliable spring clamp technology eliminates loose wiring problems caused by vibrations and thermal cycling, ensuring stable electrical continuity and enhanced safety.
The CXF4L6-60V is designed according to international industrial standards and is suitable for modern industrial electrical infrastructure where reliability, safety, and compact design are essential.
| Parameter | Specification |
|---|---|
| Model Number | CXF4L6-60V |
| Product Type | Spring Clamp Fuse Terminal Block |
| Fuse Type | Glass Fuse |
| Fuse Size | 5 x 20 mm |
| Rated Voltage | 1000 V |
| Rated Current | 10 A |
| LED Indication Voltage | 6–60V AC/DC |
| Connection Type | Spring Clamp |
| Wire Range | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide 66 |
| Product Function | Single Level Fuse with Indication |
| Wire Entry Orientation | Top |
| Width | 6 mm |
| Length | 65.4 mm |
| Height with DIN Rail | 61.3 – 68.8 mm |
| Stripping Length | 10 mm |
| Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Color | Grey |
| Operation | Screwdriver Operated |
