The CXF4L6-60V1A is a high-performance spring clamp fuse terminal block specially designed for industrial electrical panels, automation systems, PLC wiring, switchgear assemblies, instrumentation circuits, and power distribution applications. Built for reliable circuit protection and efficient electrical connectivity, this terminal block combines advanced spring clamp technology with integrated fuse indication for superior industrial performance.
Designed for modern industrial electrical systems, the CXF4L6-60V1A supports 5x20 mm glass fuses and includes a built-in LED indication system that operates within a 6–60V AC/DC range. The LED indication allows maintenance engineers and technicians to quickly identify blown fuse conditions, reducing downtime and simplifying troubleshooting operations inside electrical control panels.
The CXF4L6-60V1A uses advanced spring clamp connection technology, which provides secure and maintenance-free conductor termination. The spring mechanism is operated using a screwdriver that temporarily opens the clamp, allowing wire insertion. Once the screwdriver is removed, the conductor is automatically clamped firmly onto the current bar, ensuring strong electrical continuity and vibration-resistant performance.
This connection technology eliminates issues related to loose wiring caused by thermal cycling or mechanical vibrations, making the terminal block highly suitable for industrial environments with continuous operations and heavy machinery.
Manufactured using premium-grade polyamide insulation material, the CXF4L6-60V1A offers excellent thermal stability, electrical insulation, flame resistance, and mechanical durability. Its robust housing ensures safe and reliable performance even under demanding industrial conditions.
The compact 6 mm slim profile helps optimize space utilization inside densely populated electrical panels and control cabinets. Despite its compact design, the terminal block delivers excellent current carrying capability and reliable fuse protection performance.
The top wire entry orientation simplifies cable routing and wiring organization inside control panels. The terminal block is compatible with standard DIN 35 and DIN 35-15 mounting rails, enabling quick and secure installation in industrial electrical systems.
The CXF4L6-60V1A is widely used in:
Its integrated fuse protection system helps safeguard sensitive electrical circuits and automation equipment against overload and short-circuit conditions. The LED indication system improves maintenance efficiency by providing clear visual status monitoring of fuse conditions.
The terminal block supports conductor sizes ranging from 0.2 mm² to 4 mm² stranded conductors and up to 6 mm² solid conductors, offering excellent wiring flexibility for different industrial applications.
Its high surge voltage capacity and pollution degree rating ensure dependable performance in industrial electrical environments where voltage fluctuations and environmental stress are common.
The CXF4L6-60V1A is designed according to international industrial standards and approvals, making it suitable for industrial installations requiring reliable electrical protection, compact design, and long-term operational stability.
| Parameter | Specification |
|---|---|
| Model Number | CXF4L6-60V1A |
| Product Type | Spring Clamp Fuse Terminal Block |
| Fuse Type | Glass Fuse |
| Fuse Size | 5 x 20 mm |
| Fuse Rating | 1 A |
| Rated Voltage | 1000 V |
| Rated Current | 10 A |
| LED Indication Voltage | 6–60V AC/DC |
| Connection Type | Spring Clamp |
| Product Function | Single Level Fuse with Indication |
| Wire Range Stranded | 0.2 – 4 mm² |
| Wire Range Solid | 0.2 – 6 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide |
| Wire Entry Orientation | Top |
| Stripping Length | 10 mm |
| Width | 6 mm |
| Length | 65.4 mm |
| Height with DIN 35 x 7.5 Rail | 61.5 mm |
| Height with DIN 35 x 15 Rail | 69 mm |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Operating Method | Screwdriver |
| Color | Grey |
Provides instant visual indication of blown fuse conditions for faster troubleshooting.
Ensures maintenance-free, vibration-resistant, and secure electrical connections.
Slim 6 mm body enables high-density wiring inside industrial control panels.
Premium polyamide housing offers excellent insulation and mechanical strength.
Supports 5x20 mm glass fuse for protecting industrial electrical circuits.
Quick mounting on standard DIN rails simplifies panel assembly and maintenance.
