The CXF4L6-60VBK is a high-performance spring clamp fuse terminal block specially designed for industrial electrical panels, PLC systems, automation equipment, instrumentation circuits, switchgear assemblies, and power distribution applications. Built for reliable circuit protection and secure electrical connectivity, this terminal block combines advanced spring clamp technology with integrated LED fuse indication for efficient industrial operations.
The CXF4L6-60VBK terminal block is engineered for modern industrial electrical systems requiring compact design, fast installation, and dependable circuit protection. It supports 5x20 mm glass fuse protection, making it suitable for safeguarding sensitive electrical and automation circuits against overload and fault conditions.
One of the major advantages of the CXF4L6-60VBK is its built-in LED indication system. The LED operates within a 6–60V AC/DC range, allowing maintenance personnel to quickly identify blown fuse conditions. This feature significantly reduces troubleshooting time and improves maintenance efficiency in industrial control panels and electrical systems.
The terminal block uses advanced spring clamp connection technology for secure and maintenance-free conductor termination. The spring mechanism is operated using a screwdriver to open the clamp temporarily for wire insertion. Once the screwdriver is removed, the spring automatically clamps the conductor firmly onto the current bar, ensuring strong electrical continuity and vibration-resistant performance.
Unlike conventional screw clamp systems, the spring clamp design minimizes issues related to loose wiring caused by thermal cycling or mechanical vibrations. This makes the CXF4L6-60VBK highly suitable for industrial environments involving continuous machine operation and heavy-duty electrical applications.
Manufactured using high-quality polyamide insulation material, the terminal block provides excellent thermal resistance, flame resistance, electrical insulation, and mechanical durability. Its robust industrial-grade housing ensures reliable long-term performance even under harsh environmental conditions.
The compact 6 mm width design helps optimize space inside electrical control cabinets and switchgear assemblies. Despite its slim structure, the terminal block offers excellent current carrying capability and dependable fuse protection performance.
Its top-entry wire orientation simplifies cable routing and organized panel wiring. The terminal block supports conductor sizes up to 4 mm² stranded wires and 6 mm² solid conductors, offering flexibility for a wide range of industrial wiring applications.
The CXF4L6-60VBK is compatible with standard:
This allows quick and secure installation inside industrial electrical panels, PLC systems, and automation cabinets.
The terminal block is widely used in:
The black housing color supports organized and professional color-coded wiring systems inside industrial control cabinets, improving circuit identification and maintenance efficiency.
Its high surge voltage rating of 8 kV provides additional protection against transient electrical stress and voltage fluctuations commonly present in industrial electrical infrastructure.
The CXF4L6-60VBK is designed according to industrial electrical standards and offers dependable long-term performance for applications requiring compact fuse protection, reliable electrical connectivity, and organized industrial wiring systems.
| Parameter | Specification |
|---|---|
| Model Number | CXF4L6-60VBK |
| Product Type | Spring Clamp Fuse Terminal Block |
| Fuse Type | Glass Fuse |
| Fuse Size | 5 x 20 mm |
| Rated Voltage | 1000 V |
| Rated Current | 10 A |
| LED Indication Voltage | 6–60V AC/DC |
| Connection Type | Spring Clamp |
| Product Function | Single Level Fuse with Indication |
| Wire Range Stranded | 0.2 – 4 mm² |
| Wire Range Solid | 0.2 – 6 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Polyamide |
| Width | 6 mm |
| Length | 65.4 mm |
| Height with DIN 35 x 7.5 Rail | 61.5 mm |
| Height with DIN 35 x 15 Rail | 69 mm |
| Wire Entry Orientation | Top Entry |
| Stripping Length | 10 mm |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Operating Method | Screwdriver |
| Color | Black |
Provides instant visual indication for blown fuse detection and faster maintenance.
Ensures maintenance-free and vibration-resistant electrical connections.
Slim 6 mm structure supports high-density panel wiring arrangements.
Premium polyamide housing ensures long service life and excellent insulation.
Supports 5x20 mm glass fuse for reliable industrial electrical protection.
Quick mounting compatibility with standard industrial DIN rail systems.
