The CXG2.5 is a compact and reliable ground terminal block specially designed for secure earthing connections and safe electrical grounding in industrial automation and electrical distribution systems. Engineered for professional panel wiring and industrial safety applications, this terminal block provides dependable grounding performance and organized electrical connectivity in demanding environments.
Manufactured using premium-grade flame-retardant polyamide material with high-conductivity grounding components, the CXG2.5 delivers excellent electrical insulation, thermal resistance, and long-term mechanical durability. Its industrial-grade construction ensures stable performance even in harsh operating conditions exposed to vibration, heat, and continuous electrical load.
The terminal block supports 2.5 sq.mm conductor capacity, making it ideal for industrial grounding systems, control panels, automation cabinets, instrumentation systems, electrical distribution boards, and machine wiring applications.
One of the key highlights of the CXG2.5 is its dedicated grounding functionality, which provides secure protective earthing connections for industrial electrical systems. Proper grounding improves operational safety, protects electrical equipment from leakage current and fault conditions, and minimizes electrical hazards.
The green-yellow housing design enables quick identification of grounding circuits inside electrical panels and industrial automation systems. The color-coded structure improves organized panel wiring and simplifies maintenance and troubleshooting procedures for technicians and electricians.
Its compact modular structure allows efficient panel space utilization while maintaining clean and professional wiring arrangements. The slim body design is especially suitable for high-density industrial control panels and electrical installations requiring organized grounding systems.
The CXG2.5 features a secure screw clamp connection mechanism that ensures strong conductor retention and vibration-resistant electrical connectivity. This provides stable grounding performance and minimizes the risk of loose electrical connections during long-term industrial operation.
Its side-entry wire connection configuration simplifies conductor insertion and allows easy accessibility during installation and servicing procedures. The terminal block is fully compatible with standard DIN rail mounting systems, enabling fast and organized installation inside industrial electrical cabinets and automation panels.
The CXG2.5 is widely used across industries such as industrial automation, manufacturing plants, HVAC systems, renewable energy systems, process control industries, instrumentation engineering, machine manufacturing, and factory automation projects.
Its combination of reliable grounding capability, durable insulated construction, compact DIN rail design, and organized earthing identification makes it an ideal solution for industrial systems requiring safe and efficient electrical grounding.
The CXG2.5 delivers dependable grounding performance, organized panel integration, and long operational reliability for modern industrial electrical applications.
| Specification | Details |
|---|---|
| Product Model | CXG2.5 |
| Product Type | Ground Terminal Block |
| Conductor Capacity | 2.5 Sq.mm |
| Color | Green-Yellow |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Mounting Type | DIN Rail Mounting |
| Connection Type | Screw Clamp |
| Housing Material | Flame Retardant Polyamide |
| Grounding Function | Yes |
| Wire Entry | Side Entry |
| Tightening Torque | 0.4 Nm |
| Strip Length | 8 mm |
| Installation Type | Panel Mounted |
| Operating Temperature | -40°C to +105°C |
| Industrial Usage | Earthing & Electrical Protection |
| HSN Code | 85389000 |
| Brand | Connectwell |
| Country of Origin | India |
The CXG2.5 is suitable for industrial systems requiring secure grounding connectivity and organized earthing management.
Its dedicated grounding functionality makes it highly suitable for industrial electrical safety applications.
Provides secure grounding connectivity for industrial electrical safety systems.
Green-yellow housing simplifies earthing circuit identification and maintenance.
Secure screw clamp mechanism ensures stable and vibration-resistant conductor termination.
Space-saving modular structure supports organized electrical installations.
Quick mounting compatibility simplifies electrical panel assembly and maintenance.
Manufactured using premium insulated material for dependable long-term operation.
Robust industrial design improves reliability and reduces maintenance frequency.
The CXG2.5 is designed for industrial systems requiring safe grounding and dependable electrical protection.
Professionals prefer this terminal block because of:
Its dependable industrial performance makes it ideal for automation systems, electrical panels, and industrial grounding applications.
