The CXK2.5BK is a high-performance 2.5 sq.mm spring clamp terminal block designed for safe, reliable, and efficient electrical connections in industrial control panels, automation systems, PLC panels, switchgear assemblies, and instrumentation applications. This compact disconnect terminal block offers secure wiring, quick maintenance, and dependable circuit isolation for industrial electrical installations.
The CXK2.5BK model features a knife disconnect mechanism that allows technicians to isolate circuits during testing, troubleshooting, or maintenance without disturbing the complete wiring setup. Its spring clamp technology ensures vibration-resistant and maintenance-free connections, making it ideal for demanding industrial environments.
Designed with high-quality polyamide housing and engineered according to international standards, the CXK2.5BK terminal block ensures excellent electrical conductivity, durability, and operational safety. It is widely used in power distribution panels, process automation systems, control cabinets, machine wiring, and industrial electrical infrastructure.
The CXK2.5BK is a compact top-entry knife disconnect terminal block with spring clamp technology. It is specially designed for efficient wire termination and easy circuit disconnection during electrical maintenance and testing procedures. The spring clamp system is operated using a screwdriver, enabling quick insertion and secure clamping of conductors.
This terminal block supports stranded conductors ranging from 0.2 sq.mm to 2.5 sq.mm and is suitable for DIN rail mounting. The black-colored housing allows easy circuit identification and organized wiring in industrial control systems.
Its compact 5 mm width saves valuable panel space while maintaining excellent electrical performance. The disconnect knife mechanism provides safe isolation for current testing, signal interruption, and troubleshooting operations without removing field wiring.
| Parameter | Specification |
|---|---|
| Product Name | CXK2.5BK |
| Product Type | Knife Disconnect Spring Clamp Terminal Block |
| Color | Black |
| Rated Voltage | 1000 V |
| Rated Current | 20 A – 22 A |
| Rated Surge Voltage | 6 KV – 8 KV |
| Wire Size Range | 0.2 sq.mm to 2.5 sq.mm |
| AWG Range | 24 AWG to 12 AWG |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Connection Type | Spring Clamp |
| Housing Material | Polyamide |
| Width / Thickness | 5 mm |
| Length | 62.2 mm |
| Height with DIN 35x7.5 Rail | 38 mm |
| Height with DIN 35x15 Rail | 45.5 mm |
| Wire Entry Orientation | Top Entry |
| Operation | Screwdriver Operated |
| Application | Disconnect & Test |
| Pollution Degree | 3 |
| Stripping Length | 10 mm |
| Country of Origin | India |
The CXK2.5BK spring clamp disconnect terminal block is widely used in various industrial and commercial electrical applications, including:
Its reliable disconnect feature makes it highly suitable for applications requiring regular testing, signal isolation, and troubleshooting.
The integrated knife disconnect mechanism enables safe and easy isolation of electrical circuits during maintenance and testing procedures.
The slim 5 mm profile allows high-density terminal arrangements inside compact control panels.
Spring clamp technology eliminates the need for periodic tightening, reducing maintenance requirements.
The high-quality conductive components provide stable current flow and long-lasting electrical reliability.
Spring clamp connections maintain secure conductor contact even under heavy vibration conditions.
Quick top-entry wiring with screwdriver operation improves installation efficiency and reduces wiring time.
