The CXM2.5BU is a compact and high-performance micro spring clamp feed through terminal block designed for secure electrical connectivity in industrial automation and control systems. This DIN rail mounted terminal block is widely used in PLC panels, electrical control cabinets, instrumentation systems, switchgear assemblies, machine control panels, and process automation applications where reliable conductor termination and space-saving installation are essential.
Designed with advanced spring clamp connection technology, the CXM2.5BU provides maintenance-free and vibration-resistant conductor connections, ensuring dependable electrical performance even in demanding industrial environments. Its feed through configuration enables organized conductor continuity and efficient panel wiring management.
Manufactured using industrial-grade polyamide insulation material and high-conductivity metallic components, the CXM2.5BU offers excellent insulation strength, thermal resistance, and long operational service life. The blue housing color simplifies circuit identification and improves organized wiring layouts inside electrical panels and automation systems.
Its compact modular structure supports high-density terminal installations while maximizing available panel space in modern industrial control systems.
The CXM2.5BU feed through terminal block is specially engineered for industrial electrical systems requiring compact conductor termination and secure spring clamp connectivity. Its micro spring clamp mechanism automatically maintains constant pressure on conductors, eliminating the need for periodic tightening and reducing maintenance requirements.
The feed through design allows direct electrical continuity between connected conductors, ensuring stable current transmission and organized wiring arrangements. Its top-entry wiring orientation simplifies conductor insertion and improves installation accessibility in compact electrical control panels.
Compatible with DIN 15 rail mounting systems, the CXM2.5BU supports flexible integration into industrial automation systems, instrumentation equipment, machine control systems, and electrical distribution panels.
Its rugged industrial construction makes it suitable for continuous operation in environments exposed to vibration, heat, dust, and mechanical stress.
| Specification | Details |
|---|---|
| Model Number | CXM2.5BU |
| Product Type | Feed Through Terminal Block |
| Connection Technology | Micro Spring Clamp |
| Mounting Type | DIN Rail Mounting |
| Rated Voltage | 1000 V |
| Rated Current | 24 A |
| Rated Surge Voltage | 8 kV |
| Wire Size Range | 0.2 sq.mm to 2.5 sq.mm |
| Conductor Cross Section | 2.5 sq.mm Max |
| Housing Material | Polyamide |
| Wire Entry Orientation | Top Entry |
| Mounting Compatibility | DIN 15 Rail |
| Width / Thickness | 5 mm |
| Height | 35 mm |
| Length | 37 mm |
| Pollution Degree | 3 |
| Color | Blue |
| Operation | Screwdriver Operated |
| Industrial Usage | Automation & Control Panels |
Technical specifications verified from manufacturer and distributor sources.
The CXM2.5BU terminal block is widely used in industrial electrical systems requiring compact, secure, and maintenance-free conductor connectivity.
Its compact micro spring clamp design makes it highly suitable for high-density panel installations and organized wiring applications.
The spring clamp mechanism eliminates the need for periodic screw tightening and reduces maintenance effort.
Constant conductor pressure ensures stable current flow and secure electrical contact.
The spring clamp system maintains reliable connections even in industrial environments exposed to vibration.
Its slim modular structure supports efficient panel space utilization and organized terminal arrangements.
Tool-assisted spring clamp operation enables quick conductor insertion and simplified wiring.
The industrial-grade housing provides excellent resistance against heat and mechanical stress.
The feed through configuration supports clean and professional electrical panel layouts.
Spring clamp terminal blocks are essential in modern industrial electrical systems because they provide secure, maintenance-free, and vibration-resistant conductor connectivity. Unlike conventional screw terminals, spring clamp systems maintain constant conductor pressure over time, improving electrical reliability and reducing maintenance requirements.
The CXM2.5BU is especially suitable for automation systems, machine control equipment, and industrial control panels where dependable wiring and compact installation are important. Its compact modular design also supports high-density panel layouts used in modern industrial automation systems.
The CXM2.5BU offers an excellent combination of compact design, reliable electrical performance, industrial durability, and maintenance-free operation. Its advanced micro spring clamp technology ensures dependable conductor holding and long-term electrical stability in demanding industrial applications.
The terminal block is ideal for automation systems, PLC panels, industrial machinery, process control equipment, and power distribution systems requiring organized and secure electrical connectivity.
Its strong insulation properties, compact modular construction, and easy installation make it a trusted solution for electrical engineers, automation specialists, industrial electricians, and OEM panel manufacturers.
