CYDLF4L110-240V Double Level Feed Through Terminal Block with LED Indication is a high-performance industrial electrical connection component specially designed for multi-level wire termination, voltage monitoring, circuit indication, and structured panel wiring in industrial electrical systems. It is widely used in PLC panels, industrial control cabinets, switchgear assemblies, relay logic systems, automation systems, instrumentation panels, and electrical distribution boards where compact multi-level wiring and instant voltage indication are required.
In modern industrial electrical systems, panel builders often require both space-saving wire termination and visual circuit status monitoring in one compact component. The CYDLF4L110-240V is designed with a double level feed through terminal construction combined with LED indication, allowing secure conductor termination on multiple levels while providing instant visual indication of voltage presence in the connected circuit. This helps electricians, maintenance engineers, and panel builders quickly identify active circuits and improve troubleshooting efficiency.
The LED indication system (110–240V AC/DC) provides instant visual monitoring of circuit voltage status, making the CYDLF4L110-240V highly suitable for control panels where quick diagnostics and safer maintenance access are required. Its double level compact design also helps improve terminal density and reduce panel space usage while maintaining organized circuit interconnection.
Manufactured using industrial-grade polyamide insulation material, the CYDLF4L110-240V provides excellent electrical insulation, heat resistance, mechanical strength, and long industrial service life. Its durable construction and reliable conductive path support stable performance under heat, dust, vibration, and continuous industrial electrical operation. The DIN rail mounting design supports fast installation and secure fitment in professional industrial panel systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
In industrial electrical systems, panel builders often require:
✔ Space-saving wire termination
✔ Multi-level conductor connection
✔ Instant voltage indication
✔ Circuit status monitoring
✔ Safe troubleshooting access
✔ Compact panel wiring
✔ Organized electrical layout
✔ Reliable circuit continuity
Without an indicating terminal block, systems may face:
◆ Difficult fault detection
◆ Manual voltage testing requirements
◆ Increased maintenance time
◆ Reduced panel visibility
◆ Wiring congestion
◆ Complex troubleshooting procedures
The CYDLF4L110-240V solves these issues by providing a compact double level feed through terminal block with LED indication for structured wiring and instant circuit monitoring.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
◆ Double level feed through terminal design
◆ Integrated LED voltage indication
◆ 110–240V AC/DC indication range
◆ 4 sq.mm conductor capacity
◆ Compact space-saving construction
◆ Multi-level wire termination support
◆ DIN rail mounting design
◆ Secure conductor clamping
◆ Reliable conductive contact path
◆ Instant circuit status visibility
◆ Easy troubleshooting support
◆ Durable polyamide housing
◆ Heat-resistant body design
◆ Organized panel wiring support
◆ Long industrial service life
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLF4L110-240V works by securely terminating conductors across double terminal levels while providing visual voltage indication through its integrated LED circuit.
During operation:
✔ Conductors are inserted into connection points
✔ Clamp mechanism secures wires firmly
✔ Stable electrical contact is maintained
✔ LED glows when voltage is present
✔ Circuit status becomes visually visible
✔ Multi-level wiring supports higher terminal density
✔ Safe troubleshooting becomes easier
✔ Organized circuit interconnection is maintained
This improves both wiring efficiency and circuit monitoring in industrial applications.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLF4L110-240V improves industrial wiring by combining conductor termination with visual circuit indication.
Its design helps:
✔ Improve circuit monitoring
✔ Reduce troubleshooting time
✔ Support voltage indication
✔ Improve electrical continuity
✔ Reduce panel space usage
✔ Minimize contact resistance
✔ Support safer maintenance access
✔ Improve wiring reliability
This makes it highly useful in industrial control systems where compact wiring and instant voltage monitoring are required.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLF4L110-240V is manufactured using industrial-grade materials for dependable industrial performance.
Its construction provides:
✔ High-strength polyamide housing
✔ Excellent electrical insulation
✔ Heat-resistant body material
✔ Flame-retardant construction
✔ Integrated LED indication system
✔ Corrosion-resistant conductive parts
✔ Secure conductor clamping mechanism
✔ Compact industrial design
✔ Long service life
Its rugged construction supports stable industrial use under:
◆ Heat
◆ Dust
◆ Vibration
◆ Moisture
◆ Continuous electrical operation
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLF4L110-240V improves panel wiring efficiency by providing compact multi-level termination with voltage indication.
Its design supports:
✔ Better panel space utilization
✔ Organized conductor routing
✔ Instant voltage visibility
✔ Faster troubleshooting access
✔ Reduced wiring clutter
✔ Professional panel finishing
✔ Higher terminal density
✔ Improved maintenance convenience
This makes the CYDLF4L110-240V highly suitable for industrial electricians, automation engineers, and panel builders.
| Specification | Details |
|---|---|
| Product Model | CYDLF4L110-240V |
| Product Type | Double Level Feed Through Terminal Block with LED Indication |
| Terminal Function | Multi-Level Wire Termination & Voltage Indication |
| Terminal Color | Grey |
| LED Indication Voltage | 110–240V AC/DC |
| Rated Voltage | 1000V |
| Rated Current | 10A |
| Conductor Size | 0.2 – 4 sq.mm |
| AWG Range | 24 – 10 AWG |
| Connection Type | Spring Clamp |
| Wire Entry Type | Top Entry |
| Terminal Level | Double Level |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Industrial Grade Polyamide |
| Rated Surge Voltage | 8kV |
| Pollution Degree | 3 |
| Stripping Length | 10 mm |
| Dimensions (L x W x H) | 65.4 x 6 x 61.3 mm |
| Mechanical Strength | High |
| Heat Resistance | Yes |
| Corrosion Resistance | Yes |
| Vibration Stability | Yes |
| Service Life | Long Industrial Use |
| Main Usage | Wire Termination, Circuit Monitoring & Voltage Indication |
| Panel Benefit | Organized Wiring & Instant Circuit Visibility |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
► Double Level Wiring Design
Supports compact multi-level conductor termination.
► LED Voltage Indication
Provides instant visual circuit monitoring.
► Space Saving Terminal Block
Improves panel space utilization.
► Reliable Electrical Performance
Supports stable current flow and safe conductor connection.
► Durable Industrial Construction
Built for long-term industrial electrical use.
► Easy DIN Rail Installation
Supports quick and secure mounting.
► Professional Panel Wiring
Improves organized electrical layouts.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✔ PLC Panels
✔ Industrial Control Cabinets
✔ Switchgear Assemblies
✔ Automation Systems
✔ Relay Control Circuits
✔ Instrumentation Panels
✔ Process Automation Panels
✔ Electrical Distribution Boards
✔ Machine Wiring Systems
✔ Industrial Electrical Installations
No reviews yet.
