CYDLG2.5 Double Level Earthing Terminal Block is a compact and high-performance industrial electrical connection component specially designed for protective grounding, earth continuity, and organized multi-level panel wiring in industrial electrical systems. It is widely used in PLC panels, switchgear assemblies, control panels, automation systems, machine wiring circuits, instrumentation panels, and industrial electrical installations where secure grounding and structured earth wire connection are required. The CYDLG2.5 provides a double-level earthing terminal design, allowing compact grounding termination while saving DIN rail space in electrical panels.
In industrial electrical systems, protective grounding is essential for fault current discharge, equipment safety, and personnel protection. Without a dedicated grounding terminal block, earthing conductors may become difficult to organize, leading to untidy wiring, poor maintenance access, and reduced safety. The CYDLG2.5 solves these issues by providing a 2-level grounding terminal block with green-yellow industry-standard identification, ensuring safe and organized earth continuity in compact panel installations. Its double-level design helps improve panel space utilization while maintaining reliable grounding performance.
The CYDLG2.5 uses screw clamp connection technology, providing secure conductor retention, low resistance grounding continuity, and reliable electrical contact performance. Manufactured using industrial-grade polyamide housing, it offers excellent electrical insulation, heat resistance, mechanical strength, and long industrial service life. Its rugged construction supports stable performance under heat, vibration, dust, and continuous industrial electrical operation, making it a dependable grounding solution for professional electrical systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
In industrial electrical systems, grounding circuits often require:
✔ Protective earthing continuity
✔ Fault current discharge
✔ Equipment grounding safety
✔ Organized earth wire connection
✔ Compact panel grounding
✔ Safe electrical protection
✔ Reliable ground continuity
✔ Professional wiring organization
Without a grounding terminal block, systems may face:
◆ Untidy earth wiring
◆ Poor maintenance access
◆ Unsafe conductor termination
◆ Reduced panel organization
◆ Difficult grounding distribution
◆ Increased electrical safety risks
The CYDLG2.5 solves these issues by providing a compact double-level grounding terminal block for structured earthing continuity.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
◆ Double-level grounding terminal design
◆ 2.5 sq.mm conductor capacity
◆ Green-yellow grounding identification
◆ Screw clamp connection technology
◆ Secure conductor clamping
◆ DIN rail mounting support
◆ Low resistance earth path
◆ Compact panel wiring design
◆ Reliable grounding continuity
◆ High conductive grounding contact
◆ Durable polyamide housing
◆ Side entry wire connection
◆ Heat-resistant body construction
◆ Long industrial service life
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLG2.5 works by securely terminating grounding conductors and maintaining earth continuity through a dedicated grounding contact path.
During operation:
✔ Earth wire is inserted into terminal point
✔ Screw clamp secures conductor firmly
✔ Stable grounding continuity is maintained
✔ Low resistance earth path remains active
✔ Fault current discharge becomes safer
✔ Organized grounding layout is achieved
This improves grounding efficiency and electrical safety in industrial electrical systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLG2.5 improves industrial grounding systems by providing a dedicated structured earth terminal.
Its design helps:
✔ Improve grounding continuity
✔ Support fault current discharge
✔ Reduce wiring congestion
✔ Improve electrical safety
✔ Support compact panel layouts
✔ Reduce grounding errors
✔ Improve maintenance access
✔ Support professional earthing layout
This makes it highly useful in industrial control and electrical panel grounding systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLG2.5 is manufactured using industrial-grade materials for dependable grounding performance.
Its construction provides:
✔ High-strength polyamide housing
✔ Excellent electrical insulation
✔ Heat-resistant body material
✔ Corrosion-resistant conductive parts
✔ Screw clamp retention system
✔ Rugged industrial construction
✔ Compact double-level design
✔ Long service life
Its rugged construction supports stable industrial use under:
◆ Heat
◆ Dust
◆ Vibration
◆ Moisture
◆ Continuous industrial operation
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
The CYDLG2.5 improves electrical panel grounding organization by creating a compact multi-level grounding solution.
Its design supports:
✔ Cleaner DIN rail layouts
✔ Faster panel assembly
✔ Better grounding visibility
✔ Easier troubleshooting access
✔ Reduced conductor clutter
✔ Professional electrical finishing
✔ Structured earth continuity
✔ Improved maintenance convenienc
| Specification | Details |
|---|---|
| Product Model | CYDLG2.5 |
| Product Type | Double Level Earthing Terminal Block |
| Terminal Function | Grounding / Earthing Wire Connection |
| Terminal Color | Green-Yellow |
| Rated Voltage | 500V |
| Conductor Size | 0.2 – 2.5 sq.mm |
| Solid Conductor Max | 4 sq.mm |
| AWG Range | 24 – 12 AWG |
| Connection Type | Screw Clamp |
| Wire Entry Type | Side Entry |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Housing Material | Industrial Grade Polyamide |
| Rated Surge Voltage | 8kV |
| Pollution Degree | 3 |
| Tightening Torque | 0.4 – 0.5 Nm |
| Stripping Length | 8 mm |
| Length | 70.5 mm |
| Width | 5 mm |
| Height | 73.4 mm (DIN 35 x 15) |
| Mechanical Strength | High |
| Heat Resistance | Yes |
| Corrosion Resistance | Yes |
| Vibration Stability | Yes |
| Electrical Conductivity | Low Resistance Ground Path |
| Mounting Stability | Secure Rail Fitment |
| Service Life | Long Industrial Use |
| Main Usage | Grounding & Earthing Connection |
| Panel Benefit | Organized Grounding & Safe Earthing Distribution |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
► Double Level Grounding Design
Supports compact earthing connection in less panel space.
► Reliable Ground Continuity
Ensures stable low resistance earth connection.
► Green-Yellow Safety Identification
Supports standard industrial grounding identification.
► Durable Industrial Construction
Built for long-term industrial electrical use.
► Easy DIN Rail Installation
Supports fast and secure mounting.
► Professional Grounding Layout
Improves organized and structured earth wiring.
► Low Maintenance Operation
Designed for dependable long-term grounding performance.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
