The CYDLGF4L110-240V Spring Clamp Fuse Terminal Block is a premium industrial electrical connection component designed for safe, reliable, and efficient circuit protection in control panels, switchgear systems, automation panels, and industrial electrical installations. It combines a fuse terminal block with LED indication to provide visual monitoring of fuse status, helping engineers and technicians quickly identify blown fuses and reduce maintenance downtime. The product is engineered for applications requiring secure conductor termination, compact installation, and high electrical safety standards.
This terminal block uses spring clamp connection technology, which ensures vibration-resistant and maintenance-free wiring. Unlike traditional screw-type terminals, the spring clamp mechanism provides consistent contact pressure, reducing the risk of loose connections over time. This makes it ideal for industrial automation systems, machinery wiring, power distribution panels, PLC control systems, and electrical cabinets operating in demanding environments.
The LED indication feature (110-240V AC/DC) allows instant visual feedback regarding fuse condition and circuit status. When the fuse is blown, maintenance personnel can identify the issue quickly, reducing troubleshooting time and improving operational efficiency. This feature is especially useful in industrial control applications where uptime and safety are critical.
Built with high-quality polyamide housing, the CYDLGF4L110-240V offers excellent insulation properties, flame resistance, and mechanical durability. It is suitable for DIN rail mounting and supports compact panel design, making it a preferred solution for OEM panel builders, industrial electricians, and automation system integrators. Its compact design helps save wiring space while maintaining easy accessibility for installation and fuse replacement.
The terminal block is designed for use with 5x20 mm fuse links and provides effective overcurrent protection in electrical circuits. It supports conductor cross-sections up to 4 sq.mm, making it versatile for a wide range of industrial wiring applications. With a rated voltage of 1000V and rated current of 10A, it is capable of handling industrial-grade electrical loads while ensuring safe operation.
Whether used in control systems, process automation, machine manufacturing, electrical distribution boards, or industrial instrumentation, the CYDLGF4L110-240V Fuse Terminal Block delivers excellent reliability, safety, and performance. Its compact structure, spring clamp technology, LED fuse indication, and DIN rail compatibility make it a dependable component for modern industrial electrical systems.
| Specification | Details |
|---|---|
| Product Name | CYDLGF4L110-240V Fuse Terminal Block |
| Type | Spring Clamp Fuse Terminal Block |
| Fuse Size | 5 x 20 mm |
| LED Indication Voltage | 110-240V |
| Rated Voltage | 1000V |
| Rated Current | 10A |
| Conductor Capacity | 4 sq.mm |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Connection Type | Spring Clamp |
| Housing Material | Polyamide |
| Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Wire Entry | Top Entry |
| Product Function | Single Level Fuse with Indication |
| Terminal Thickness | 6 mm |
| Approx Length | 65.4 mm |
| Application | Electrical Panels, Automation Systems, Control Panels |
The CYDLGF4L110-240V is widely used in:
